Поз.
Артикул
Описание
5
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
8
UNION NUT LINE CONNECTION
11
GLAND LINE CONNECTION
14
T-FITTING 3/2-WAY VALVE
17
FITTING , Replaced By: A0009970171
17
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
20
SCREW
20
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
23
WASHER
26
SHUT-OFF COCK
26
SHUT-OFF COCK
29
REPAIR KITTO 000 429 14 31,5 116581
29
CLAMP , Replaced By: A3604300143
29
CLAMP , Replaced By: N916016008200
29
CLAMP ,K 147121, Replaced By: N000000000319
29
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
32
FITTING , Replaced By: A0009970171
32
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
32
ADAPTER FITTING , Replaced By: A0009970271
32
FITTING FROM BRAKE BOOSTER,"A" CONNECTION,TO VALVE,"V" CONNECTION, UP TO IDENT NO. 840080 EXCEPT FOR 500001-599999
35
SEAL RING LINE CONNECTION
35
SEAL RING , Replaced By: N007603012121
35
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
38
FITTING , Replaced By: A0019972372
38
FITTING SHUTTLE VALVE,CONNECTION: "20"
41
NUT CHECK VALVE TO AIR RESERVOIR
44
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
44
THRUST RING CHECK VALVE TO AIR RESERVOIR
47
O-RING CHECK VALVE TO AIR RESERVOIR
50
BRAKE LINE COUPLING
53
THRUST RING , Replaced By: A0004292184
53
SEAL RING"WABCO"
56
SCREW SHUT-OFF COCK TO BRACKET
59
SPACER RING
62
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
65
NUT , Replaced By: N304032010002
65
NUT
68
CONNECTION FITTING ,880809
68
FITTING , Replaced By: A0039978972
68
FITTING , Replaced By: A0029905971
68
FITTING (PARTS KIT),LINE RUPTURE
71
BRACKET
71
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
71
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
74
SCREW , Replaced By: N304017008021
74
SCREW PIPE CLAMP
77
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
80
NUT
83
CLAMP DELIVERY AND SUCTION LINES TO STEERING
83
CLAMP , Replaced By: A6739950001
83
CLAMP LINE MOUNTING
83
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
83
CLAMP ,K 147121, Replaced By: N000000000319
83
CLAMP , Replaced By: N916016008200
83
CLAMP , Replaced By: A3604300143
86
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
86
BRACKET LINE MOUNTING
86
BRACKET , Replaced By: A3184280240
89
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
92
WASHER PROTECTIVE PLATE TO FRONT EXHAUST PIPE
95
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
98
NUT BALL PIVOT TO LEVER
999
SPRINGTO 000 429 16 31,4 940458
999
SPRINGTO 000 429 16 31,4 940458
999
SEAL RINGTO 000 429 16 31,4 940458
999
HANDLETO 000 429 16 31,4 940458
999
SEAL RINGTO 000 429 16 31,4 940458
999
BRACKET , 872988
999
BRACKET , 872989
999
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
999
ELBOW FITTING
