Поз.
Артикул
Описание
5
FRAME
5
FRAME
25
SIDE MEMBER LEFT
40
SIDE MEMBER RIGHT
55
BRACKET COUPLING PIN
57
ANGLE COUPLING MOUTH
75
STRUT COUPLING MOUTH
85
COUPLING PIN
87
FASTENER TO SECURE PIN
95
FRONT SPRING BRACKET ,822031, Replaced By: A3463225001, +002A3469900014, +002A3879900214, +004N000934016003
95
FRONT SPRING BRACKET FRONT,822032
95
FRONT SPRING BRACKET FRONT,822032
105
FRONT SPRING BRACKET , Replaced By: A3463225003, +002N000961014055
105
FRONT SPRING BRACKET REAR
105
FRONT SPRING BRACKET REAR
150
REAR SPRING BRACKET , Replaced By: A3873250001, +004N000961016119
150
REAR SPRING BRACKET FRONT
155
HELPER SPRING BRACKET , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3893250117
155
HELPER SPRING BRACKET , Replaced By: A6843250017
155
HELPER SPRING BRACKET FRONT
160
REAR SPRING BRACKET REAR
195
SIDE MEMBER AUXILIARY FRAME,LEFT
200
SIDE MEMBER RIGHT
205
ANGLE LEFT OUTSIDE
207
ANGLE RIGHT OUTSIDE
215
ANGLE LEFT AND RIGHT FRONT
220
ANGLE LEFT AND RIGHT CENTRAL
225
ANGLE REAR LEFT AND RIGHT
240
BRACKET AUXILIARY FRAME TO FRAME
250
BRACKET AUXILIARY FRAME TO FRAME
260
COVER PLATE PLATE TO SIDE MEMBER
270
WASHER PLATE TO SIDE MEMBER
999
NUT TORSION BAR TO BEARING BRACKET,5 904661
999
NUT , Replaced By: N910113016001
999
NUT , Replaced By: N910113014000
999
NUT , Replaced By: N910113012003
999
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
999
NUT , Replaced By: N910113010000
999
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
999
LOCK WASHER FITTING TO BRACKET
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
NUT CONSOLE TO SUPPORT
999
NUT STEERING SUPPORT TO FRAME
999
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
999
NUT SUPPORT TO SIDE MEMBER
999
NUT STRAP TO BRACKET
999
RIVET12X58 MM, TO BE ADAPTED DURING ASSEMBLY
999
RIVET REAR CROSS MEMBER 12X42 MM
999
SCREW CONSOLE TO FRAME
999
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X50
999
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
999
HEXAGON HEAD BOLT , Replaced By: A0029902704
999
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
999
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
999
NUT BRACKET TO SIDE MEMBER,K 035196
999
NUT
999
SCREW BRACKET TO SIDE MEMBER
999
WASHER MOUNTING USED FOR FRAME CONNECTION PARTS
999
WASHER , Replaced By: N007349013005
999
WASHER BEARING BRACKET TO FRAME
999
WASHER STRUT TO CROSS MEMBER
999
WASHER , Replaced By: N007349010007
999
SCREW CONSOLE TO SIDE MEMBER M 16X1.5X48
999
SCREWM 16X16X24X42
999
SCREW , Replaced By: N000961016118
999
SCREW , Replaced By: N308676016020
999
SCREW , Replaced By: N308676016007
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW STRUT TO FRAME M 14X1.5X42
999
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
999
SCREW BRACKET TO SIDE MEMBER M 12X38
999
SCREW CONSOLE TO SIDE MEMBER
999
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
999
SCREW BRACKET TO FRAME M 12X35
999
SCREW , Replaced By: N308676012026
999
SCREW , Replaced By: N308676012012
999
SCREW STRUT TO SIDE MEMBER M 12X55
999
SCREW , Replaced By: N000960012384
999
NUT , Replaced By: N308673016001
999
NUT , Replaced By: N308673016001
999
NUT , Replaced By: N308673014001
999
NUT STRAP TO SUPPORT
999
NUT , Replaced By: N304032010002
999
SCREW SUPPORT TO CROSS MEMBER M 10X28
999
SCREW , Replaced By: N304017010002
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
FITTED SCREWM 18X19X33X55
999
FITTED SCREWM 18X19X38X60
999
FITTED SCREWM 18X19X25X45
999
FITTED SCREWM 10X11X25X38
999
FITTED SCREWM 18X19X57X85
999
FITTED SCREWM 10X11X24X40
999
FITTED SCREWM 10X11X14X28
999
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
999
WASHER , Replaced By: N000125015019
999
WASHER
999
WASHER RADIATOR TO RUBBER MOUNTING
999
WASHER , Replaced By: N000125010532
999
SCREWM 12X13X58X80
999
SCREWM 12X13X63X85
999
SCREWM 16X17X24X44
999
SCREWM 14X15X18X35
999
SCREWM 16X16X38X90
999
SCREWM 12X13X25X42
999
SCREWM 16X18X38X60
999
SCREWM 12X13X12X29
999
SCREWM 16X18X26X48
999
SCREWM 12X13X23X40
999
SCREWM 12X13X13X30
999
SCREWM 16X16X20X45
999
SCREWM 16X18X63X85
999
SCREW FRONT SPRING FRONT BRACKET TO SIDE MEMBER M 16X55
999
SCREW , Replaced By: N000961018043
999
SCREWM 18X18X23X45
999
SCREWM 12X12X17X32
999
SCREWM 12X12X15X30
999
SCREWM 14X14X18X34
999
SCREWM 16X16X32X50
999
SCREWM 16X16X30X48
999
SCREWM 16X16X20X38
999
SCREWM 12X12X13X28
999
SCREWM 12X12X11X26
999
SCREW , Replaced By: N000961016118
999
SCREWM 16X16X22X40
999
SCREW , Replaced By: N308676016020
999
SCREW , Replaced By: A3229903101
999
SCREWM 12X12X10X25
999
SCREWM 10X11X26.5X46
999
SCREWM 14X15X31X48
999
SCREWM 14X15X35X52
999
SCREWM 12X13X35X52
999
SCREWM 14X14X32X50
999
SCREW , Replaced By: A0009906314
999
SCREWM 12X13X15X32
999
SCREWM 14X15X19X36
999
SCREWM 14X15X29X46
999
SCREWM 14X15X17X34
999
SCREWM 14X15X27X44
999
SCREWM 12X13X21X38
999
SCREWM 16X17X22X42
999
SCREW PLATE TO SIDE MEMBER
999
SCREWM 14X15X21X38
999
SCREWM 14X15X15X32
999
SCREWM 14X14X24X42
999
SCREWM 12X14X13X35
999
SCREWM 12X13X18X35
999
SCREW FRONT SPRING FRONT BRACKET TO SIDE MEMBER
999
SCREWM 16X18X18X40
999
BODY SUPPORT CAB, RIGHT
999
BODY SUPPORT CAB,LEFT
999
SCREWM 14X14X27X45
999
STRUT FRAME
999
SCREWM 14X14X18X32
999
SCREWM 14X14X22X40
999
SCREW , Replaced By: A3169900014
999
SCREWM 14X14X17X35
999
SCREW , Replaced By: A0029908201
999
SCREW , Replaced By: A3959900501
999
SCREW , Replaced By: N308676012013
999
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
999
RIVET , Replaced By: N910005012026
999
RIVET , Replaced By: N910005012023
999
RIVET , Replaced By: N910005012020
