Поз.
Артикул
Описание
3
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
3
LINE , Replaced By: A0005516256
20
UNION NUT BUTT SCREW CONNECTION
20
UNION NUT AIR COMPRESSOR LINE CONNECTION
23
GLAND LINE CONNECTION
25
THRUST RING BUTT SCREW CONNECTION
28
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
28
SEAL RING , Replaced By: N007603012121
34
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
37
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
37
HOSE , Replaced By: A0009872827
40
SLEEVE LINE CONNECTION
40
SLEEVE , Replaced By: N915062006000
43
UNION NUT LINE CONNECTION
43
UNION NUT , Replaced By: N915017008100
47
GLAND LINE CONNECTION
58
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
58
CLAMP ,K 147121, Replaced By: N000000000319
58
CLAMP , Replaced By: N916016008200
58
CLAMP , Replaced By: A3604300143
60
SCREW BRACKET TO COVERING
60
SCREW , Replaced By: N000000001145
63
NUT PUMP TO BRACKET
63
NUT , Replaced By: N913004006001
67
HOSE FROM FITTING TO RIGHT DIAPHRAGM CYLINDER 8 X 14 MM, ORDER BY THE METER4 940458
69
CLAMP HOSE TO FITTING
88
RESERVOIR40L,276 MM,8.5 BAR
88
RESERVOIR , Replaced By: A0034322501
92
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
92
PAD , Replaced By: A3634750320
95
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
98
FITTING SHUTTLE VALVE,CONNECTION: "20",5 727399
107
SEAL RING 2/2-WAY VALVE,CONNECTION: "20"
112
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
112
VALVE , Replaced By: A0024310706
112
VALVE , Replaced By: A0024310706
118
REPAIR KIT SEAL RING TO 001 431 38 06,BOSCH, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
122
FITTING RELAY VALVE,CONNECTION: "40",5 359430
122
FITTING , Replaced By: A0029979572
122
FITTING RELAY VALVE,CONNECTION: "1,2"
128
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
131
RESERVOIR30L,246 MM,12.5 BAR
131
RESERVOIR , Replaced By: A0034321801
138
T-FITTING
138
FITTING PRESSURE REGULATOR,CONNECTION "2.1",4 967998
138
T-FITTING , Replaced By: N074317000100
145
VALVE (CHECK VALVE), 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
145
VALVE (CHECK VALVE), 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
148
THRUST RING CHECK VALVE TO AIR RESERVOIR
148
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
152
O-RING CHECK VALVE TO AIR RESERVOIR
155
NUT CHECK VALVE TO AIR RESERVOIR
159
STRAP AIR RESERVOIR TO FRAME
162
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
162
PAD , Replaced By: A3634750320
165
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
165
SCREW PLUG , Replaced By: N000908022011
167
SEAL RING LINE CONNECTION
334
BRACKET PLASTIC LINES IN ENGINE COMPARTMENT
336
SCREW PIPE CLAMP
336
SCREW , Replaced By: N304017008021
338
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
338
NUT , Replaced By: N913004008001
342
BRACKET BATTERY CABLE TO FRAME
346
SCREW END PIECE TO EXHAUST PIPE M 10X25
349
NUT STRAP TO BRACKET
349
NUT , Replaced By: N910113010000
351
FITTING SHUTTLE VALVE
351
FITTING , Replaced By: A0029971372
353
WASHER LINE MOUNTING
357
NUT BRACKET TO SIDE MEMBER
359
NUT RETURN
361
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
361
SEALING RING. SEAL RING DELIVERY LINE TO PUMP
999
COVER"WABCO", NOT USED
999
COVER SUPPLY, RED "WABCO"
999
SEAL RING"WABCO"
999
SEAL RING , Replaced By: A0004296930
999
SEAL RING , Replaced By: A0004292184
999
BRAKE LINE COUPLINGTO 000 429 38 30
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE BOSCH
999
REPAIR KIT"KNORR"
999
VALVE , TO BE EXHAUSTED UP TO CHASSIS 4 230076, Replaced By: A0004308581
999
REPAIR KITTO 000 430 57 81,43 81,WABCO,0020,0120
999
T-FITTING LUBRICATING LINE TO DISTRIBUTOR
999
BUSHING , Replaced By: N915062009000
999
SPRING , Replaced By: A0009935205
999
SPRINGBOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
999
VALVE , Replaced By: A0024297244
999
VALVE (OVERFLOW VALVE),REAR CARRIAGE SECONDARY CONSUMING UNITS "WABCO"
999
VALVE , Replaced By: A0024297244
999
VALVE OVERFLOW VALVE
999
CUPTO 002 431 04 06,BOSCH
999
REPAIR KITTO 001 429 52 44
999
REPAIR KITBOSCH
999
REPAIR KITTO 000 429 37 30
999
REPAIR KITTO 001 431 34 05,4 375193
999
SEAL RINGTO 001 431 37 05,4 375193
999
FITTING , Replaced By: A0039978972
999
LOOM TIE LINE MOUNTING 280 MM
999
LOOM TIE LINE MOUNTING
999
FITTING SPRING LOAD ACCUMULATOR CYLINDER,4 412126
999
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
999
VALVE OVERFLOW VALVE WITH RETURN FLOW GRAU
999
VALVE (OVERFLOW VALVE),4 9119185 116581
999
REPAIR KIT VALVE KIT TO 001 431 37 05,4 375193
999
REPAIR KITTO 001 431 37 05,4 375193
999
REPAIR KITTO 000 429 63 30
999
REPAIR KIT BOOT TO 001 431 38 06,BOSCH, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KIT BOOT TO 001 431 15 06,BOSCH
999
REPAIR KITTO 000 429 78 30,4 434236
999
REPAIR KIT SEAL RING TO 001 431 15 06,BOSCH
999
REPAIR KITTO 001 431 48 05,4 375193
999
FITTING (PARTS KIT),LINE RUPTURE
999
FITTING DELIVERY LINE TO PUMP
999
FITTING ,4 412020
999
GASKET KIT SEAL RING TO 001 431 58 06,BOSCH
999
FITTING , Replaced By: A0029905971
999
SEAL RINGTO 000 429 38 30
999
SEAL RING"GRAU"
999
SEAL RING18.72X2.62 MM,WABCO,002 0,012 0
999
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
999
PLUG EXHAUST BRAKE VALVE, CONNECTION: "20"
999
BRACKET , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3872950440
999
LINE FROM PRESSURE REGULATOR TO SLIDE, LENGTH AVAILABLE 3000 MM
999
LINE , Replaced By: A3434293608, +001A0009973873, +001N003861015004
999
BRACKET LEFT
999
BRACKET RIGHT
999
BRACKET , Replaced By: A3812950440
999
CLAMP LINE MOUNTING
999
CLAMP , Replaced By: A6739950001
999
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
999
BRACKET EXHAUST PIPE SUSPENSION
999
CLAMP DELIVERY AND SUCTION LINES TO STEERING
999
SCREW CLAMP MOUNTING M 6X16
999
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
LOCK RINGTO 001 431 37 05,4 375193
999
LOCK RING52X2 MM
999
SCREW CAB FLOOR COVERING M 6X25
999
SCREW , Replaced By: N304017010002
999
CONNECTION FITTING ,880809
999
SCREW , Replaced By: N000000001146
999
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
999
FITTING , Replaced By: A0009970171
999
FITTING , Replaced By: A0009907070
999
SCREW BRACKET TO SIDE MEMBER
999
RIVET12X58 MM, TO BE ADAPTED DURING ASSEMBLY
999
SLEEVE LINE CONNECTION
