Поз.
Артикул
Описание
140
VALVE PARKING BRAKE VALVE GRAU
140
VALVE PARKING BRAKE VALVE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
140
VALVE , TO BE EXHAUSTED UP TO CHASSIS 4 230076, Replaced By: A0004308581
142
HANDLETO 000 430 85 81,WABCO,004 0
144
GASKET KIT PARKING BRAKE VALVE GRAU
144
GASKET KIT PARKING BRAKE VALVE GRAU
146
REPAIR KITTO 000 430 57 81,43 81,WABCO,0020,0120
146
REPAIR KITTO 000 430 57 81,43 81,WABCO,0020,0120
146
REPAIR KITTO 000 430 85 81,WABCO,004 0
148
SEAL RING FUEL LINE TO FEED PUMP
150
FITTING
150
FITTING , Replaced By: A0039979972
152
FITTING HYDRAULIC LINE TO BRACKET,K 130132
154
NUT SHOCK ABSORBER TO LOWER BEARING BRACKET
156
HOSE FROM FITTING TO RIGHT DIAPHRAGM CYLINDER 8 X 14 MM, ORDER BY THE METER4 940458
158
CLAMP LINE CONNECTION
160
FITTING (PARTS KIT),LINE RUPTURE
160
FITTING , Replaced By: A0029905971
160
FITTING , Replaced By: A0039978972
162
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
162
CLAMP ,K 147121, Replaced By: N000000000319
162
CLAMP , Replaced By: N916016008200
162
CLAMP , Replaced By: A3604300143
164
VALVE TRAILER BRAKE,5 116581 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
166
REPAIR KIT
168
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
170
T-FITTING AT HAND BRAKE VALVE, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927 UP TO CHASSIS 872788 EXCEPT FOR, 500033-599999
170
T-FITTING AIR RESERVOIR I
172
NUT CHECK VALVE TO AIR RESERVOIR
172
NUT CHECK VALVE TO AIR RESERVOIR
174
THRUST RING CHECK VALVE TO AIR RESERVOIR
174
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
176
O-RING CHECK VALVE TO AIR RESERVOIR
178
SEAL RING LINE CONNECTION
180
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
182
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
182
FITTING , Replaced By: A0009970171
184
BRACKET
186
BRACKET
188
SCREW END PIECE TO EXHAUST PIPE M 10X25
188
SCREW BRACKET TO SIDE MEMBER
188
SCREW , Replaced By: N304017010002
190
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
192
NUT
192
NUT , Replaced By: N304032010002
194
SCREW
194
SCREW BRACKET TO LEFT SIDE MEMBER
196
LOCK WASHER FITTING TO BRACKET
198
NUT STRAP TO SUPPORT
200
SEAL RING LINE CONNECTION
202
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
204
FITTING BRACKET TO RIGHT SIDE MEMBER
204
FITTING ,966010
206
NUT CHECK VALVE TO AIR RESERVOIR
208
SHUT-OFF COCK , Replaced By: A0004291431
208
SHUT-OFF COCK
208
SHUT-OFF COCK
216
REPAIR KITTO 000 429 14 31,5 116581
218
BRACKET
220
SPACER TUBE VIBRATION ABSORBER TO BRACKET 39 MM, TO BE ADAPTED DURING ASSEMBLY
220
SPACER TUBE VIBRATION ABSORBER TO BRACKET 39 MM, TO BE ADAPTED DURING ASSEMBLY
220
SPACER TUBE , Replaced By: A3210720053
222
SCREW
222
SCREW VALVE TO BRACKET M 8X55
222
SCREW , Replaced By: N304017008043
224
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
226
NUT
228
SCREW VALVE TO BRACKET
228
SCREW VALVE TO BRACKET, Replaced By: N304014008002
230
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
232
NUT
234
BRACKET BATTERY CABLE TO FRAME
234
BRACKET BATTERY CABLE TO FRAME
236
SCREW REAR EXHAUST PIPE TO MUFFLER
236
SCREW END PIECE TO EXHAUST PIPE M 10X25
238
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
240
NUT
240
NUT , Replaced By: N304032010002
242
SEAL RING LINE CONNECTION
244
FITTING SHUTTLE VALVE,CONNECTION: "20"
244
FITTING , Replaced By: A0019972372
248
NUT CHECK VALVE TO AIR RESERVOIR
250
THRUST RING CHECK VALVE TO AIR RESERVOIR
250
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
252
O-RING CHECK VALVE TO AIR RESERVOIR
254
BRAKE LINE COUPLING
254
BRAKE LINE COUPLING AT REAR CROSS MENBER
254
BRAKE LINE COUPLING AT REAR CROSS MENBER
254
BRAKE LINE COUPLING , Replaced By: A0004297530
254
BRAKE LINE COUPLING AT REAR CROSS MENBER
254
BRAKE LINE COUPLING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0004296730
258
SEAL RINGTO 000 429 75 30
264
VALVE DISCTO 000 429 48 30
266
SPRINGTO 000 429 16 30
270
GASKETTO 000 429 16 30
274
VALVE TAPPETTO 000 429 16 30
276
SNAP RINGTO 000 429 16 30
280
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
284
SPRING CAPSULETO 000 429 16 30
286
SEAL RINGTO 000 429 16 30
288
SEAL RINGTO 000 429 16 30
290
PIN
294
THRUST RING CHECK VALVE TO AIR RESERVOIR
294
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
296
REPAIR KIT BRAKE LINE COUPLING TO 000 429 27 30,966011
298
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
326
BRACKET OIL LINE MOUNTING
326
BRACKET , Replaced By: A3464296040
328
SCREW BRACKET TO CROSS CONNECTION STRUT
328
SCREW , Replaced By: N304017008034
330
WASHER EXHAUST MUFFLER TO STRAP
330
WASHER , Replaced By: N000125008443
332
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
334
NUT
999
VALVE CONE , Replaced By: A0004290391
999
VALVE CONEBOSCH
999
COVERTO 000 429 48 30
999
COVERWABCO
999
CONNECTOR ,966010
999
SPRINGTO 000 429 29 30
999
SPRINGTO 000 429 16 31,4 940458
999
SPRINGTO 000 429 16 31,4 940458
999
SEAL RINGTO 000 429 16 31,4 940458
999
ELBOW FITTING , Replaced By: A0004294638
999
REPAIR KITKNORR
999
COVERTO 000 429 16 30,BOSCH
999
NUTTO 000 429 16 30
999
VALVE PARTTO 000 429 16 30
999
VALVE DISCTO 000 429 48 30
999
SWITCH , Replaced By: A0005456009
999
T-FITTING AT AIR RESERVOIR
999
SPRINGTO 000 429 16 30
999
HANDLETO 000 429 16 31,4 940458
999
VALVETO 000 429 29 30
999
BRAKE VALVE
999
REPAIR KITWABCO
999
SEAL RINGTO 000 429 16 31,4 940458
999
PLUG EXHAUST BRAKE VALVE, CONNECTION: "20"
999
BRACKET MOUNTING USED FOR COMPRESSED AIR LINES,974675
999
BRACKET
999
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
999
SEAL RING , Replaced By: N007603012121
