Поз.
Артикул
Описание
5
AIR CLEANER OIL BATH
5
AIR CLEANER OIL BATH
9
FILTER BOWL
14
FILTER ELEMENT
19
GASKET INSIDE
24
GASKET OUTSIDE
29
BRACKET OIL BATH AIR CLEANER
29
BRACKET OIL BATH AIR CLEANER
38
AIR INTAKE PIPE
38
AIR INTAKE PIPE
42
BUSHING INTAKE MANIFOLD
46
COVERING INTAKE MANIFOLD
53
BOOT OIL BATH AIR CLEANER
53
HOSE CLAMP FROM AIR CLEANER TO TRANSVERSE INTAKE PIPE, Replaced By: A0019951910
53
CLAMP , Replaced By: A0059971490
57
AIR INTAKE PIPE
57
AIR INTAKE PIPE
59
BOOT INTAKE PIPE TO AIR CLEANER
999
PART NAME MISSING DIA., 128 MM
999
ANGLE BUMPER,LEFT
999
ANGLE BUMPER,RIGHT
999
ANGLE BUMPER,RIGHT
999
ANGLE BUMPER,LEFT
999
SCREW INTAKE PIPE TO AIR BAFFLE
999
SCREW LICENSE PLATE TO BRACKET,4 300861
999
SCREW SHIFT CASE TO SLOTTED GATE
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
SCREW , Replaced By: N304017008027
999
NUT BALL PIVOT TO LEVER
999
NUT , Replaced By: N308673014001
999
SCREW , Replaced By: N308676012026
999
SCREW CONSOLE TO SIDE MEMBER
999
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
999
SCREW , Replaced By: N308676014020
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
999
NUT
999
NUT BRACKET TO SIDE MEMBER,K 035196
999
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
999
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
999
HOSE FROM AIR INTAKE PIPE TO OIL BATH AIR CLEANER 80 MM, UP TO IDENT NO. 676464 EXCEPT FOR 500001-599999 ORDER BY THE METER
999
NUT SUPPORT TO SIDE MEMBER
999
NUT BRACKET TO SIDE MEMBER
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
999
NUT , Replaced By: N910113014001
