Поз.
Артикул
Описание
142
HOUSING CLUTCH
142
HOUSING , Replaced By: A3462505105, +008N000960018013
142
HOUSING CLUTCH
147
BUSHING RELEASE SHAFT,BOTTOM
154
BUSHING RELEASE SHAFT,BOTTOM 24X27 MM
159
BUSHING TOP
165
BUSHING TOP
169
FELT RING
174
COVER PLATE
179
REPAIR KIT , DELIVER ADDITIONALLY:AS REQUIRED 1X 317 293 01 77-06 77, Replaced By: A3632500114
179
SHAFT (PARTS KIT),RELEASE SHAFT, DELIVER ADDITIONALLY:AS REQUIRED 1X 317 293 01 77-06 77
179
RELEASE SHAFT
184
WASHER AS REQUIRED 1.3 MM
184
WASHER AS REQUIRED 1.00 MM
184
WASHER AS REQUIRED 1.10 MM
184
WASHER AS REQUIRED 1.20 MM
184
WASHER AS REQUIRED 0.90 MM
184
WASHER AS REQUIRED 0.80 MM
189
FELT RING
194
SPACER WASHER RELEASE SHAFT,BOTTOM
199
LOCK RING RELEASE SHAFT,BOTTOM
204
RELEASE YOKE , Replaced By: A3452937111
209
SPACER TUBE
214
WASHER
219
ROLL PIN. CLAMPING SLEEVE
224
WASHER
229
LEVER LEFT
234
LEVER RIGHT
239
LOCK
244
DISC SPRING WORM TO BRACKET,5 143211 ON VEHICLES HAVING MERCEDES BENZ BODY
249
FITTED WASHER AS REQUIRED 1.0 MM
249
SHIM. FITTED WASHER HYDRAULIC LINE MOUNTING PARTS
249
FITTED WASHER AS REQUIRED 1.5 MM
256
WASHER RADIATOR TO RUBBER MOUNTING
256
WASHER , Replaced By: N000125010532
262
SCREW CLAMP TO DRAG LINK TO 344 338 73 45
268
LOCK WASHER FITTING TO BRACKET
272
SCREW RELEASE LEVER TO SHAFT, 024,026,027,028,121,122 5 095724 065,131,132 5 104252
272
SCREW , Replaced By: N304017012002
276
LOCK WASHERROCKINGER TYP 59 G140,59 G150
281
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
281
NUT , Replaced By: N308673016001
286
COVER ,079773
292
SCREW , Replaced By: N304017006020
292
SCREW LICENSE PLATE TO BRACKET
297
NUT BALL PIVOT TO LEVER
304
SPRING
309
PRESSURE PLATE CLUTCH BRAKE
314
BRAKE LINING
319
RIVET CLUTCH BRAKE
319
RIVET
325
BRAKE DISC
331
GUIDE , Replaced By: A3432540216
331
GUIDE
337
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
342
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
347
SPACER TUBE GUIDE TO BELL HOUSING
353
FRICTION PIECE
357
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
361
SCREW , Replaced By: N304017010050
361
SCREW , Replaced By: N304017010055
367
RELEASE COLLAR
372
SEAL RINGTO 000 550 00 83
377
SCREW-IN FITTING RELEASE COLLAR LUBRICATION
387
RELEASE BEARING
393
HOSE RELEASE BEARING LUBRICATION 170 MM
398
DOUBLE TAPER RING RELEASE COLLAR LUBRICATION
403
UNION SCREW RELEASE COLLAR LUBRICATION
408
BULKHEAD FITTING RELEASE BEARING LUBRICATION
413
SPRING WASHER BEARING BRACKET TO SIDE MEMBER,4 207081
418
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
423
GREASE NIPPLE FOR SPRING
429
PROTECTIVE PLATE BOTTOM
435
WASHER RADIATOR TO RUBBER MOUNTING
435
WASHER , Replaced By: N000125010532
440
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
446
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SLEEVE CLUTCH PRESSURE PLATE
999
SPRING SUSPENDED BELOW LEAF SPRING
999
HOUSING , UP TO IDENT NO. 764484 EXCEPT FOR 500001-599999, Replaced By: A3462505005, +008N000960018013
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
SCREW , Replaced By: N000960018109
999
SCREW , Replaced By: N308676018009
999
SCREW BELL HOUSING TO TRANSMISSION
999
SCREWM 18X18X33X55
999
LOCK PLATE RELEASE LEVER TO SHAFT
999
LOCK WASHER SHOCK ABSORBER TO CONSOLE, FOR USE WITH MEDIUM-LENGTH MERCEDES-BENZ CAB,FOR USE WITH LONG MERCEDES-BENZ CAB OR LESS MERCEDES-BENZ CAB
