Поз.
Артикул
Описание
100
SHIFTING CYLINDER P.T.O. SHIFTING CYLINDER
100
SHIFTING CYLINDER , Replaced By: A0002609863
101
SEALING CORD
102
PULL ROD
103
SEAL RING59X50X2 MM
106
SPACER RING AS REQUIRED 10.00 MM
109
SPACER WASHER AS REQUIRED 3.00 MM
110
SPACER WASHER AS REQUIRED 2.00 MM
111
GASKET SHIFTING CYLINDER
112
COVER
113
COMBINATION BOLT , Replaced By: N304017008021, +001N000137008204
113
SCREW PIPE CLAMP
114
BOOT
119
SCREW (THROTTLE SCREW)
120
CYLINDRICAL PIN
120
DOWEL PIN , Replaced By: N000007008102
121
SCREW , Replaced By: N304017008021
121
SCREW PIPE CLAMP
123
VALVE24V,4 237957 IN CASE OF R.H.D.,EXCHANGE BREATHER AND SCREW PLUG AGAINST ONE ANOTHER PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
124
SEAL RING ,4 237957
125
SEAL RING ,4 237957
130
AIR CLEANER
132
BRACKET ,4 237957
137
SPACER RING BRACKET TO REAR AXLE HOUSING,5 244591
138
SCREW , Replaced By: N000933010192
138
SCREW SHIFTING ROD TO SHIFT LEVER
140
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
141
WASHER
143
SWITCH , Replaced By: A0002600771
143
SWITCH
147
PLATE
154
SPRING
155
WASHER BRACKET TO CROSS MEMBER
157
LOCK RING STEERING WHEEL HEIGHT ADJUSTMENT,4 188879
158
COVERING
164
PULL ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER
164
PULL ROD , Replaced By: N900331008421
166
NUT , Replaced By: N304032008006
166
NUT
167
BALL SOCKET ROD TO BALL PIVOT
168
FITTING , Replaced By: A0039979072
168
FITTING , Replaced By: A0029906071
168
TS DOUBLE FITTING SOLENOID VALVE
170
SEAL RING LINE CONNECTION
171
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
171
LINE , Replaced By: A0004296201
174
UNION NUT
175
GLAND , Replaced By: A0019901667
175
SEAL CONE
999
VALVE , Replaced By: A0002608057
999
VALVE P.T.O.
999
COVER SHIFTING ROD, WITH AK 6-90 UP TO TRANSMISSION 068147,WITH AK 6-80 UP TO TRANSMISSION 279573
999
TRANSMISSION CASE COVER REAR, WITH AK 6-90 FROM TRANSMISSION 068148,WITH AK 6-80 FROM TRANSMISSION 279574
999
TRANSMISSION CASE COVER COUNTERSHAFT,FRONT,279826
999
TRANSMISSION CASE
999
LOCK DRIVE SHAFT,047093
999
RING AS REQUIRED 8.20 MM,047093
999
RING AS REQUIRED 7.60 MM,047093
999
RING AS REQUIRED 7.40 MM,047093
999
RING AS REQUIRED 7.20 MM,047093
999
RING AS REQUIRED 7.00 MM,047093
999
RING AS REQUIRED 6.80 MM,047093
999
RING AS REQUIRED 6.40 MM,047093
999
GASKET , ONLY FOR TRANSMISSION HAVING SWIVEL-MOUNTED CYLINDER
999
GEAR (DRIVE GEAR),P.T.O. Z 52
999
SPACER WASHER AS REQUIRED 2.60 MM, 10/50 UP TO TRANSMISSION 279825,50/60 FROM TRANSMISSION 000001
999
OIL BAFFLE
999
CASE , Replaced By: A0002643001, +001N007603018102, +001N007604018101
999
CASE
999
RING HALF , Replaced By: A0002620577
999
RING HALF AS REQUIRED 8.00 MM,047093
999
RING HALF AS REQUIRED 7.80 MM,047093
999
RING HALF , Replaced By: A0002620677
999
RING HALF , Replaced By: A0002620777
999
RING HALF , Replaced By: A0002620877
999
RING HALF , Replaced By: A0002620977
999
RING HALF , Replaced By: A0002621077
999
RING HALF , Replaced By: A0012620530
999
RING HALF AS REQUIRED 6.50 MM,047093
999
RING HALF , Replaced By: A0002621177
999
RING HALF AS REQUIRED 4.05 MM
999
RING HALF AS REQUIRED 6.20 MM,047093
999
RING HALF AS REQUIRED 6.10 MM,047093
999
RING HALF AS REQUIRED 6.00 MM
999
RING HALF AS REQUIRED 6.70 MM,047093
999
RING HALF , Replaced By: A0012621130
999
RING HALF AS REQUIRED 7.10 MM,047093
999
RING HALF AS REQUIRED 7.30 MM,047093
999
RING HALF AS REQUIRED 7.50 MM,047093
999
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
999
HOSE365 MM
999
FLEXIBLE SHAFT FRONT 2495 MM,011336
999
MAGNET
999
NUT SWITCH TO APPARATUS PLATE
999
SHELL TWO-SPEED REAR AXLE CONTROL,4 188089
999
SHELL TWO-SPEED REAR AXLE CONTROL,4 188089
999
NUT , Replaced By: A0029906251
999
BUTTON SWITCH,928519
999
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
999
PIN BUSHING , Replaced By: A0075458226
999
SWITCH , Replaced By: A3445457111
999
CLAMP CABLE HARNESS MOUNTING,4 494992
999
BOOT *** 2.5 MM2
999
REPAIR KITHERION,94171034/0711/24V,94172034/0711
999
PLASTIC PIPE RISING PIPE 4X6 MM
999
T-FITTING FITTING,5 461950
999
PLUG , Replaced By: A0009973435
999
PLUG , Replaced By: A0009977535
999
SCREW PLUG P.T.O. HOUSING
999
PLUG , Replaced By: A3529970032
999
SCREW PLUG OIL FILLING, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
999
REPAIR KITTO 001 997 34 36,002 997 58 36,
999
RING HALF AS REQUIRED 6.60 MM,047093
999
RING HALF AS REQUIRED 6.90 MM,047093
999
SPACER WASHER AS REQUIRED 0.50 MM
999
SPACER WASHER AS REQUIRED 0,30 MM
999
SPACER WASHER AS REQUIRED 0.20 MM
999
FLEXIBLE SHAFT , Replaced By: A0015427407
999
FLEXIBLE SHAFT2700 MM
999
PIN BUSHING HOUSING 4-POLE
999
REPAIR KIT , Replaced By: A0012608357
999
CYLINDR. ROLLER BEARING , Replaced By: N005412770009
999
SEALING CORD , Replaced By: A0119979145
999
WASHER AS REQUIRED 0.50 MM,279825
999
LOCK AS REQUIRED 2.40 MM
999
LOCK AS REQUIRED 2.30 MM
999
LOCK AS REQUIRED 2.20 MM
999
LOCK AS REQUIRED 2,55 MM
999
LOCK , Replaced By: A0099947141
999
LOCK AS REQUIRED 2.65 MM
999
LOOM TIE TO MOUNT PLASTIC PIPING
999
FITTING , Replaced By: N915058004000
999
SPACER WASHER AS REQUIRED 2.30 MM,279825
999
SPACER WASHER AS REQUIRED 2.35 MM, 10/50 UP TO TRANSMISSION 279825,50/60 FROM TRANSMISSION 000001
999
SPACER WASHER AS REQUIRED 2.40 MM,279825
999
SPACER WASHER AS REQUIRED 2.45 MM,279825
999
SPACER WASHER AS REQUIRED 2.50 MM,279825
999
SPACER WASHER AS REQUIRED 2.55 MM, 10/50 UP TO TRANSMISSION 279825,50/60 FROM TRANSMISSION 000001
999
SPACER WASHER , Replaced By: A0002638552
999
SPACER WASHER AS REQUIRED 2.65 MM, 10/50 UP TO TRANSMISSION 279825,50/60 FROM TRANSMISSION 000001
999
SPACER WASHER , Replaced By: A3432611152
999
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
999
PIN BUSHING HOUSING UNIPOLAR
999
PIN BUSHING HOUSING UNIPOLAR
999
NEEDLE BEARING , Replaced By: A0002683050
999
CYLINDR. ROLLER BEARING , Replaced By: N005412770009
999
NEEDLE BEARING , Replaced By: A0059818010
999
SCREW
999
NUT POTENTIOMETER TO INSTRUMENT PANEL
999
TRANSMISSION AK 6-80(HILL GEAR)1ST SPEED RATIO1:9.0,6TH SPEED RATIO1:1.0, FOR TYPE L-LK-LS 1621/1921,L/LA 1624 FOR COMPONENT PARTS,SEE SPARE PARTS LIST PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
TRANSMISSION AK 6-80(HILL GEAR)1ST SPEED RATIO1:9.0,6TH SPEED RATIO1:1.0, FOR TYPES L-LK-LS 1621/1921 L/LA 1624 FOR COMPONENT PARTS,SEE SPARE PARTS LIST
999
TRANSMISSIONAK 6-80
999
TRANSMISSIONAK 6-80
999
TRANSMISSION , Replaced By: A0032611800, +001A3362603705
999
TRANSMISSION , Replaced By: A0032611800, +001A3662600405
999
TRANSMISSION , Replaced By: A0032611900, +001A3362603805
999
TRANSMISSION , Replaced By: A0032611900, +001A3362604005
999
SEAL RING SHIFTING SHAFT,TOP, 10/50 UP TO TRANSMISSION 279825,50/60 FROM TRANSMISSION 000001
999
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
999
SEAL RING
999
SEAL RING , Replaced By: A0069978847
999
SEAL RING SHIFT CASE,FRONT
999
SEAL RING , Replaced By: A0089973347
999
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
999
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
999
LOCK AS REQUIRED 65X2.6 MM
999
NUT ,928519
999
CLAMP WIRE CABLE TO CAB, FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB
999
BEFESTIGUNGSSCHELLE. CLAMP LINES TO ENGINE
999
CLAMP , Replaced By: N072571001035
999
HANDLE
999
SPACER RING BRACKET TO TRANSMISSION,5 215322
999
SPACER TUBE ,4 237958
999
CLAMP , Replaced By: A0005460875
999
BOOT SHIFT LEVER BEARING COVERING
999
LEVER CLUTCH OPERATION, ON L FROM IDENT NO. 008464 ALSO INSTALLED ON 008448-008455
999
CONNECTOR SHIFT LEVER TO LEVER
999
SHIFT LEVER FOR HILL GEAR AND FRONT AXLE DRIVE
999
ROD
999
ELECTRIC CABLE
999
ELECTRIC CABLE
999
BUSHING
999
BUSHING PAWL TO ROD END,5 443047
999
COVERING
999
SHAFT GEARSHIFT MECHANISM
999
BEARING BRACKET
999
BEARING BRACKET FROM SHIFT LEVER TO P.T.O.
999
P.T.O.N 80/10
999
P.T.O.N 80/10
999
P.T.O. , Replaced By: A3662600405, +001A3662620045
999
P.T.O. RATIO: 1.51 X N MOTOR
999
TRANSMISSION , Replaced By: A0032611800
999
TRANSMISSION , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0032611900
999
TRANSMISSION CASE , Replaced By: A0002612301, +001A0002611619, +004N000933010129
999
CONNECTOR AS REQUIRED 88.50 MM,TO 366 264 00 32
999
FOLLOWER , Replaced By: A0002640846
999
SPACER WASHER AS REQUIRED 1.60 MM
999
RING HALF ,047092, Replaced By: A0002643729, +001A0002620373
999
SPACER WASHER AS REQUIRED 1.40 MM
999
COVER , Replaced By: A0009977535
