Поз.
Артикул
Описание
2
BEARING BRACKET
5
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
5
SCREW , Replaced By: N308676014020
8
NUT BRACKET TO SIDE MEMBER
8
NUT , Replaced By: N910113014001
11
SHACKLE , Replaced By: A3353200437
11
SHACKLE TORSION BAR
11
SHACKLE STABILIZER
14
BUSHING TORSION BAR TO BEARING BRACKET
17
WASHER STABILIZER, 756168
20
NUT TORSION BAR TO BEARING BRACKET
23
TORSION BAR
24
RUBBER MOUNTING TORSION BAR
26
REPAIR KIT TORSION BAR TO BEARING BRACKET
26
REPAIR KIT , Replaced By: A3633200228
29
BRACKET STABILIZER
32
SCREW BRACKET TO FRAME M 12X35
32
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
32
SCREW , Replaced By: N308676012026
35
NUT SUPPORT TO SIDE MEMBER
38
BEARING RIGHT
38
BEARING LEFT
41
BUSHING TORSION BAR TO BEARING BRACKET
44
DISC SPRING TORSION BAR TO BEARING BRACKET
47
NUT TORSION BAR TO BEARING BRACKET
50
U-BOLT FRONT SPRINGS TO FRONT AXLE 275 MM
50
U-BOLT , Replaced By: A3043311925
50
U-BOLT FRONT SPRINGS TO FRONT AXLE 245 MM
999
PIN , Replaced By: A6203200228
999
PIN , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE4 707618, Replaced By: A3875860232
999
SHACKLE ,4 707917, Replaced By: A3873260647, +001A3873260281
999
CONSOLE , Replaced By: A3933200678
999
CONSOLE , Replaced By: A3933261163, +001N000961016081
999
SPACER WASHER , Replaced By: A3873230252
999
SHACKLE ,4 707917, Replaced By: A3933260547, +001A3873260281
999
SPACER WASHER SHACKLE TO BEARING BRACKET,5 904660
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
999
NUT COMBINATION CYLINDER TO BEARING BRACKET
999
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
