Поз.
Артикул
Описание
13
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
15
UNION NUT LINE CONNECTION
17
GLAND LINE CONNECTION
201
VALVE , TO BE EXHAUSTED UP TO CHASSIS 4 230076, Replaced By: A0004308581
201
VALVE PARKING BRAKE VALVE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
201
VALVE PARKING BRAKE VALVE GRAU
202
HANDLETO 000 430 85 81,WABCO,004 0
203
GASKET KIT PARKING BRAKE VALVE GRAU
204
REPAIR KITTO 000 430 85 81,WABCO,004 0
204
REPAIR KITTO 000 430 57 81,43 81,WABCO,0020,0120
205
SEAL RING FUEL LINE TO FEED PUMP
206
FITTING , Replaced By: A0039979972
206
FITTING
207
VALVE TRAILER BRAKE,5 116581 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
208
REPAIR KIT
209
ELBOW FITTING , Replaced By: A0004294638
209
ELBOW FITTING COMBINATION CYLINDER,CONNECTION: "12"
211
T-FITTING AIR RESERVOIR I
211
T-FITTING AT HAND BRAKE VALVE, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927 UP TO CHASSIS 872788 EXCEPT FOR, 500033-599999
215
NUT CHECK VALVE TO AIR RESERVOIR
217
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
217
THRUST RING CHECK VALVE TO AIR RESERVOIR
219
O-RING CHECK VALVE TO AIR RESERVOIR
221
SEAL RING LINE CONNECTION
223
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
225
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
225
FITTING , Replaced By: A0009970171
227
BRACKET
229
SCREW BRACKET TO LEFT SIDE MEMBER
229
SCREW
231
LOCK WASHER FITTING TO BRACKET
233
NUT STRAP TO SUPPORT
235
SCREW , Replaced By: N304017010002
235
SCREW BRACKET TO SIDE MEMBER
237
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
239
NUT
239
NUT , Replaced By: N304032010002
241
ADAPTER FITTING FLUID RESERVOIR TO BRACKET
243
NON-RETURN VALVE. VALVE WITH CHECK VALVE WABCO,5 433388
243
VALVE (CHECK VALVE)
245
VALVE SEAT RINGWABCO,5 433388
247
BUSHINGWABCO,5 433388
248
REPAIR KITWABCO
249
SEAL RING LINE CONNECTION
251
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
252
FITTING SHUTTLE VALVE,CONNECTION: "20"
252
FITTING , Replaced By: A0019972372
253
SEAL RING LINE CONNECTION
254
SHUT-OFF COCK
254
SHUT-OFF COCK
255
REPAIR KITTO 000 429 14 31,5 116581
257
SEAL RING LINE CONNECTION
259
FITTING SHUTTLE VALVE,CONNECTION: "20"
259
FITTING , Replaced By: A0019972372
259
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
261
NUT CHECK VALVE TO AIR RESERVOIR
263
THRUST RING CHECK VALVE TO AIR RESERVOIR
263
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
265
O-RING CHECK VALVE TO AIR RESERVOIR
267
CONNECTOR ,966010
267
FITTING SHUTTLE VALVE,CONNECTION: "20"
267
FITTING , Replaced By: A0019972372
267
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
267
FITTING ,966010
268
BRAKE LINE COUPLING
269
BRAKE LINE COUPLING AT REAR CROSS MENBER
269
BRAKE LINE COUPLING AT REAR CROSS MENBER
269
BRAKE LINE COUPLING AT REAR CROSS MENBER
269
BRAKE LINE COUPLING AT REAR CROSS MENBER
269
BRAKE LINE COUPLING AT REAR CROSS MENBER
269
BRAKE LINE COUPLING AT REAR CROSS MENBER
269
BRAKE LINE COUPLING AT REAR CROSS MENBER
269
BRAKE LINE COUPLING , Replaced By: A0004297530
269
BRAKE LINE COUPLING AT REAR CROSS MENBER
269
BRAKE LINE COUPLING AT REAR CROSS MENBER
269
BRAKE LINE COUPLING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0004296730
270
VALVE DISCTO 000 429 48 30
270
VALVE DISCTO 000 429 48 30
270
VALVE DISCTO 000 429 48 30
271
SPRINGTO 000 429 16 30
271
SPRINGTO 000 429 16 30
271
SPRINGTO 000 429 16 30
272
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
273
GASKETTO 000 429 16 30
273
GASKETTO 000 429 16 30
273
GASKETTO 000 429 16 30
274
SEAL RINGTO 000 429 16 30
274
SEAL RINGTO 000 429 16 30
274
SEAL RINGTO 000 429 16 30
274
SEAL RINGTO 000 429 16 30
274
SEAL RINGTO 000 429 16 30
274
SEAL RINGTO 000 429 16 30
275
PIN
275
PIN
275
PIN
276
COVERWABCO
276
COVERWABCO
276
COVERWABCO
277
SEAL RINGTO 000 429 75 30
277
SEAL RINGTO 000 429 75 30
277
SEAL RINGTO 000 429 75 30
278
REPAIR KIT BRAKE LINE COUPLING TO 000 429 27 30,966011
278
REPAIR KITWABCO
278
REPAIR KITWABCO
278
REPAIR KITKNORR
278
REPAIR KITKNORR
278
REPAIR KITWABCO
279
BRACKET
280
SCREW REAR EXHAUST PIPE TO MUFFLER
281
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
283
NUT BRACKET TO SUPPORT AND TO END PIECE
285
SCREW CABLE HARNESS MOUNTING
285
SCREW BRACKET TO EXHAUST PIPE BRACKET
285
SCREW , Replaced By: N304017008024
289
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
291
NUT
293
NUT CHECK VALVE TO AIR RESERVOIR
341
FITTING (PARTS KIT),LINE RUPTURE
341
FITTING , Replaced By: A0029905971
341
FITTING , Replaced By: A0039978972
341
CONNECTION FITTING ,880809
349
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
999
VALVE CONEBOSCH
999
COVERTO 000 429 48 30
999
SPRINGTO 000 429 16 31,4 940458
999
SPRINGTO 000 429 16 31,4 940458
999
SEAL RINGTO 000 429 16 31,4 940458
999
VALVE (OVERFLOW VALVE) WESTINGHOUSE
999
VALVE
999
VALVE , Replaced By: A0014296344
999
VALVE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
BRAKE VALVE TWO-CIRCUIT, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
RESERVOIR ,5 934167, Replaced By: A0034322501, +001A6554320073
999
RESERVOIR , Replaced By: A0034321101
999
RESERVOIR , Replaced By: A0034322301
999
RESERVOIR SERVICE BRAKE 30 L, Replaced By: A0034321801, +001A6554320073
999
RESERVOIR , Replaced By: A0004324301
999
NUTTO 000 429 16 30
999
VALVE PARTTO 000 429 16 30
999
VALVE DISCTO 000 429 48 30
999
SWITCH , Replaced By: A0005456009
999
REPAIR KITTO 000 429 63 44,000 429 59 44
999
REPAIR KIT OVERFLOW VALVE TO 003 429 09 44,WABCO
999
REPAIR KITTO 001 431 00 05,001 431 24 05
999
REPAIR KIT , Replaced By: A0015860843
999
REPAIR KIT COMPRESSED AIR CYLINDER TO 001 431 35 05,001 431 94 05,WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
T-FITTING AT AIR RESERVOIR
999
T-FITTING 3/2-WAY VALVE
999
HANDLETO 000 429 16 31,4 940458
999
BRAKE VALVE
999
BRAKE VALVE
999
FITTING , Replaced By: N915062006000
999
SEAL RINGTO 000 429 16 31,4 940458
999
PLUG EXHAUST BRAKE VALVE, CONNECTION: "20"
999
BRACKET
999
STRAP
999
UNION NUT
999
FITTING
999
FITTING
