Поз.
Артикул
Описание
4
RADIATORBEHR
4
RADIATOR , Replaced By: A3465005803, +001A3465015982
8
RADIATOR CAPTO 346 500 50 03,4 2993464 787608
12
GASKET
16
RADIATOR CAPTO 346 500 54 03,4 299346
20
GASKETTO 346 500 54 03
24
SUPPORT , 007551
28
SHIM , L FROM CHASSIS 000151 ALSO INSTALLED ON 000087-000092,000098-000107,000143,LP FROM CHASSIS 000067
32
RUBBER MOUNTING
36
WASHER RADIATOR TO RUBBER MOUNTING
36
WASHER , Replaced By: N000125010532
40
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
44
NUT BRACKET TO SUPPORT AND TO END PIECE
48
RADIATOR STRUT
48
RADIATOR STRUT , Replaced By: A3385000045
52
SPACER TUBE RADIATOR STRUT TO SUPPORT AND TO CAB
56
RUBBER RING SHOCK ABSORBER MOUNTING
60
WASHER COMPRESSED AIR LINE TO BRACKET
60
WASHER , Replaced By: N009021006208
64
NUT BRACKET TO SUPPORT AND TO END PIECE
68
AIR BAFFLE
74
HOSE FROM INLET,OR COOLING WATER LINE,TO THERMOSTAT
78
HOSE LOWER COOLING WATER LINE TO RADIATOR & OIL COOLER
82
HOSE DE-AERATION
86
HOSE HEATING PIPE
90
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
999
CLAMP , Replaced By: N000000000672
999
CLAMP , Replaced By: N000000000667
999
NUT , Replaced By: N913004008001
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
SCREW VALVE TO BRACKET M 8X55
999
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
999
SCREW , Replaced By: N304017008043
999
CLAMP HOSE FASTENING 50-70X13 MM
999
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
999
HOSE DE-AERATION AT UPPER COOLING WATER PIPE, FROM IDENT NO. 4 742813 EXCEPT FOR 4 743433-4 745018,4 745860-4 746037
999
RADIATORHAUGG,4 787609
999
RADIATOR ,4 787608, Replaced By: A3465005903, +001A3465015982
999
RADIATOR , Replaced By: A3465005403
999
SUPPORT , Replaced By: A3355001127
999
HOSE OVERFLOW
999
RADIATOR CAP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0005014215
999
RADIATOR CAPTO 346 500 54 03,4 299345
999
VALVE WATER DRAIN
