Поз.
Артикул
Описание
234
HOUSING , UP TO IDENT NO. 764484 EXCEPT FOR 500001-599999, Replaced By: A3462505005, +008N000960018013
243
BUSHING RELEASE SHAFT,BOTTOM
252
BUSHING RELEASE SHAFT,BOTTOM 24X27 MM
261
BUSHING TOP
270
BUSHING TOP
279
FELT RING
288
COVER PLATE
297
SCREW BELL HOUSING TO TRANSMISSION
306
LOCK WASHER BELL HOUSING TO TRANSMISSION
315
SHAFT (PARTS KIT),RELEASE SHAFT, DELIVER ADDITIONALLY:AS REQUIRED 1X 317 293 01 77-06 77
324
WASHER AS REQUIRED 0.80 MM
324
WASHER AS REQUIRED 1.20 MM
324
WASHER AS REQUIRED 1.10 MM
324
WASHER AS REQUIRED 0.90 MM
324
WASHER AS REQUIRED 1.3 MM
324
WASHER AS REQUIRED 1.00 MM
333
FELT RING
342
SPACER WASHER RELEASE SHAFT,BOTTOM
351
LOCK RING RELEASE SHAFT,BOTTOM
360
RELEASE YOKE , Replaced By: A3452937111
369
SPACER TUBE
378
WASHER
387
CLAMPING SLEEVE
396
WASHER
405
LEVER LEFT
414
LEVER RIGHT
423
LOCK
432
DISC SPRING WORM TO BRACKET,5 143211 ON VEHICLES HAVING MERCEDES BENZ BODY
441
FITTED WASHER AS REQUIRED 1.5 MM
441
FITTED WASHER AS REQUIRED 1.0 MM
441
SHIM. FITTED WASHER HYDRAULIC LINE MOUNTING PARTS
450
WASHER , Replaced By: N000125010532
459
SCREW CLAMP TO DRAG LINK TO 344 338 73 45
468
SCREW BRACKET TO TRANSMISSION
477
LOCK WASHER FITTING TO BRACKET
486
LOCK WASHERROCKINGER TYP 59 G140,59 G150
495
NUT , Replaced By: N308673016001
504
COVER ,079773
513
SCREW , Replaced By: N304017006020
522
NUT BALL PIVOT TO LEVER
531
SPRING
540
PRESSURE PLATE CLUTCH BRAKE
549
BRAKE LINING
558
RIVET
558
RIVET CLUTCH BRAKE
567
BRAKE DISC
576
GUIDE
585
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
594
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
603
SPACER TUBE GUIDE TO BELL HOUSING
612
FRICTION PIECE
621
SCREW , Replaced By: N304017010050
630
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
639
RELEASE COLLAR
648
SCREW-IN FITTING RELEASE COLLAR LUBRICATION
657
SEAL RINGTO 000 550 00 83
666
SPRING LOCK RELEASE COLLAR TO RELEASE YOKE
675
RELEASE BEARING
684
HOSE RELEASE BEARING LUBRICATION 170 MM
693
DOUBLE TAPER RING RELEASE COLLAR LUBRICATION
702
UNION SCREW RELEASE BEARING LUBRICATION
711
BULKHEAD FITTING RELEASE BEARING LUBRICATION
720
SPRING WASHER BEARING BRACKET TO SIDE MEMBER,4 207081
729
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
738
GREASE NIPPLE FOR SPRING
747
PROTECTIVE PLATE BOTTOM
756
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
765
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
774
WASHER , Replaced By: N000125010532
