Поз.
Артикул
Описание
490
BRACKET BRACKET TO SIDE MEMBER, TO BE ADAPTED DURING ASSEMBLY
492
CLAMP LINE MOUNTING
494
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
496
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
498
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
500
NUT BALL PIVOT TO LEVER
502
EXPANSION PLUG CAB REAR PANEL
504
GROMMET
612
VALVE HAND BRAKE VALVE WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
612
VALVE HAND BRAKE VALVE KNORR, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
614
REPAIR KITTO 000 430 66 81,000 430 67 81, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
614
REPAIR KIT , Replaced By: A0004305760
614
REPAIR KIT , Replaced By: A0034303881
614
REPAIR KITTO 000 430 55 81,WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
616
FITTING
618
SEAL RING FUEL LINE TO FEED PUMP
620
BRACKET HAND BRAKE VALVE
622
SHIM VALVE TO CAB, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
624
SCREW ACCELERATOR PEDAL TO CAB M 6X25
626
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
628
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
630
NUT BALL PIVOT TO LEVER
632
COVERING AT HAND BRAKE VALVE
634
SCREW BUSHING AND LEVER TO CAB
636
WASHER , Replaced By: N000125008443
638
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
640
VALVE RELAY VALVE KNORR
640
VALVE PARKING BRAKE, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
640
VALVE (RELAY VALVE) GRAU
642
SEAL RING22.3X2.4 MM,GRAU
644
VALVE SEATGRAU
646
SEAL RINGTO 000 429 28 95,GRAU
648
SEAL RING28X2 MM,GRAU
650
SEAL RING86X2 MM,GRAU
652
GASKET34X2X6 MM,GRAU
654
REPAIR KITWABCO
654
REPAIR KITKNORR
656
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
658
NUT , Replaced By: N304032008006
660
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
662
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
664
T-FITTING
666
NUT CHECK VALVE TO AIR RESERVOIR
668
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
668
THRUST RING CHECK VALVE TO AIR RESERVOIR
670
O-RING CHECK VALVE TO AIR RESERVOIR
672
BRACKET RELAY VALVE,5 484806
674
SCREW END PIECE TO EXHAUST PIPE M 10X25
676
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
678
NUT BRACKET TO SUPPORT AND TO END PIECE
680
HOSE FROM FITTING TO RIGHT DIAPHRAGM CYLINDER 8 X 14 MM, ORDER BY THE METER4 940458
682
CLAMP HOSE TO FITTING
684
T-FITTING 3/2-WAY VALVE,CONNECTIONS: "30,50"
686
PLUG TWO-CIRCUIT BRAKE VALVE,CONNECTIONS: "21,22", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
688
LOCK NUT BRANCH-OFF TO BUS STOP BRAKE
690
BRACKET OIL LINE MOUNTING
690
BRACKET , Replaced By: A3464296040
692
BRACKET JOINT TO FRAME,4 645187
694
BRACKET OIL LINE MOUNTING
696
CLAMP ,K 147121, Replaced By: N000000000319
696
CLAMP , Replaced By: N916016008200
696
CLAMP , Replaced By: A3604300143
696
CLAMP , Replaced By: A6739950001
696
CLAMP DELIVERY AND SUCTION LINES TO STEERING
698
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
700
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
702
NUT BALL PIVOT TO LEVER
704
SCREW , Replaced By: N308676012026
706
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
708
WASHER
710
NUT SPARE WHEEL TO CROSS MEMBER
999
ADJUSTER
999
PLUGTO 694 420 71 18/72 18
999
CUPTO 007 420 68 18,WABCO
999
CUP , Replaced By: A0004215386
999
CUPKNORR
999
CUPKNORR
999
DIAPHRAGMTO 007 420 68 18,69 18,70 18,WABCO
999
DIAPHRAGM , Replaced By: A0004314128
999
DIAPHRAGMTO 008 420 60 18,62 18,KNORR
999
DIAPHRAGM , Replaced By: A0004314128
999
DIAPHRAGMTO 008 420 61 18,009 420 22 18
999
PISTONTO 006 420 94 18,BOSCH
999
CUPGRAU
999
NUT BEARING BRACKET TO BRAKE ANCHOR
999
PANHEAD RIVET BRAKE LINING TO BRAKE SHOE 15 MM
999
PLUGBOSCH
999
PLUGTO 009 420 22 18,008 420 20 18
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
CUPBOSCH/WABCO
999
CUP , Replaced By: A0004216186
999
SEAL RING , Replaced By: A0149972247
999
REPAIR KITKNORR
999
SEAL RING INSIDE BEARING BRACKET
999
SEAL RING , Replaced By: A0129973747
999
SEAL RING BRAKE SHOE PIN TO BRAKE ANCHOR
999
WHEEL BRAKE CYLINDER (DIAPHRAGM CYLINDER) BOSCH
999
WHEEL BRAKE CYLINDER (DIAPHRAGM CYLINDER) WABCO
999
WHEEL BRAKE CYLINDER (DIAPHRAGM CYLINDER) GRAU
999
WHEEL BRAKE CYLINDER (DIAPHRAGM CYLINDER) KNORR
999
WHEEL BRAKE CYLINDERKNORR,4 304304
999
SEAL RING , Replaced By: A0129973647
999
SEAL RING OUTSIDE BEARING BRACKET
999
SEAL RING OUTSIDE BEARING BRACKET
999
SEAL RING INSIDE BEARING BRACKET
999
SEAL RING OUTSIDE BEARING BRACKET
999
SEAL RING INSIDE BEARING BRACKET
999
SEAL RING , Replaced By: A0129974147
999
BUSHING OUTSIDE
999
BUSHING INSIDE
999
REPAIR KIT BRAKE SHOE ROLLER
999
PLUG
999
PROTECTIVE PLATE , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A3574201844
999
PROTECTIVE PLATE , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A3574201744
999
RIVET BRAKE LINING 15 MM
999
PLUG PROTECTIVE PLATE
999
SPACER WASHER ADJUSTER,AS REQUIRED 1.50 MM
999
SPACER WASHER ADJUSTER,AS REQUIRED 2.00 MM
999
SPACER WASHER ADJUSTER,AS REQUIRED 2.50 MM
999
SPACER WASHER ADJUSTER,AS REQUIRED 0.50 MM
999
SPACER WASHER ADJUSTER
999
BRAKE ANCHOR BRAKE SHOE BEARING
999
STOP WASHER ADJUSTER TO BEARING BRACKET
999
BRAKE LINING , MAN AXLE, Replaced By: A3464237610
999
BRAKE LINING , MAN AXLE, Replaced By: A3464236110
999
BRAKE LINING , MAN AXLE, Replaced By: A3464236210
999
BRAKE LINING , MAN AXLE, Replaced By: A3464236310
999
WASHER , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: N000988017100
999
SCREW BRAKE ANCHOR PLATE AND SUPPORTING SLEEVE TO JOINT HOUSING M 16X50
999
SCREW FRONT WHEEL BRAKE TO STEERING KNUCKLE
999
SCREW SHOCK ABSORBER TO TOP BRACKET
999
SCREW BEARING BRACKET TO BRAKE ANCHOR
999
SPRING BRAKE SHOE RELEASE SPRING,INSIDE
999
LOCK , Replaced By: A9429940009
999
LOCK BRAKE SHOE TO BRAKE ANCHOR PLATE, USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185 UP TO CHASSIS FB588185,FROM CHASSIS FB588186,SEE SPARE PARTS LIST 743.0
999
BRAKE LINING (PARTS KIT) (ASBESTOS-FREE BRAKE LINING) 15.00 MM,8X 349 421 09 10),4 337020 FROM IDENT NO. 4 337021, SEE SEPARATE SPARE LIST 739.001
999
BRAKE LINING , Replaced By: A3494211410
999
BRAKE LINING (PARTS KIT) (ASBESTOS-FREE BRAKE LINING) 17.00 MM,8X 349 421 11 10),4 337020 FROM IDENT NO. 4 337021, SEE SEPARATE SPARE LIST 739.001
999
PROTECTIVE PLATE WITH BEAD AND BRAKE LINING WEAR INDICATOR
999
PROTECTIVE PLATE WITHOUT BEAD, WITH BRAKE LINING WEAR INDICATOR
999
PIN COMBINATION CYLINDER TO SLACK ADJUSTER
999
SPACER WASHER ADJUSTER TO BRAKE CAMSHAFT
999
SPACER WASHER BRAKE SHOE TO BRAKE ANCHOR
999
NUT , Replaced By: A0009905750
999
SCREW REAR WHEEL BRAKE TO REAR AXLE M 16X45
999
SCREW , Replaced By: A3469900804
999
PIN , Replaced By: A6584210074
999
BRACKET LINE TO REAR AXLE, NOT USED
999
BEARING BRACKET LEFT
999
BEARING BRACKET , Replaced By: A3894210906
999
BRAKE ANCHOR RIGHT
999
BRAKE SHOE , FIRST EXHAUST STOCK OF OLD PARTS UP TO FRONT AXLE E 128437, Replaced By: A3934202519
999
BRAKE ANCHOR , Replaced By: A3464213106
999
PIN BRAKE SHOE TO BRAKE ANCHOR
999
SPRING , Replaced By: A6179931110
999
SPRING BRAKE SHOE IN WELDED VERSION
999
BRAKE CAMSHAFT WITH LUBRICATING BORE,LEFT
999
BRAKE CAMSHAFT WITH LUBRICATING BORE,RIGHT
999
PIN
999
LOCK BRAKE SHOE TO BRAKE ANCHOR
999
LOCK PLATE BRAKE SHOE TO BRAKE ANCHOR PLATE, UP TO CHASSIS 588185,FROM CHASSIS FB588186,SEE SPARE PARTS LIS T,BM 732.7
999
LOCK RING SHOCK ABSORBER TO BRACKET,1D 006005
999
LOCK RING ADJUSTER TO BRAKE CAMSHAFT
999
SCREW BRACKET TO STEERING
999
GREASE NIPPLE PROTECTIVE TUBE
999
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
999
SCREW , Replaced By: A3469901304
999
SCREW CROSS MEMBER TO SIDE MEMBERS M 16X65
