Поз.
Артикул
Описание
8
BEARING BRACKET
21
BUSHING
25
GREASE NIPPLE
29
SCREW
41
SCREW BRACKET TO RETARDER
41
SCREW BRACKET TO FRAME M 12X35
43
NUT BRACKET TO SIDE MEMBER,XB209706
43
NUT SUPPORT TO SIDE MEMBER
45
PEDAL CLUTCH
49
SPRING CLUTCH
53
PEDAL (BRAKE PEDAL),668122
53
PEDAL
53
PEDAL BRAKE PEDAL, USED WITH HYDRAULIC BRAKE UP TO CHASSIS 588185
56
PEDAL BRAKE PEDAL,GB718836
58
BUSHING
58
BUSHING
62
PEDAL PLATE CLUTCH PEDAL
62
PEDAL PLATE BRAKE PEDAL,B 714733
62
PEDAL PLATE BRAKE PEDAL,GB718835
66
SEAL WASHER
70
SCREW , Replaced By: N304017010040
74
PAD BRAKE PEDAL
74
PAD CLUTCH PEDAL,GB718836
74
PAD BRAKE AND CLUTCH LEVERS
79
STOP CLUTCH PEDAL AND BRAKE PEDAL
83
LOCK WASHER , Replaced By: N912004010102
87
SCREW CROSS MEMBER TO SIDE MEMBERS
91
SCREW STOP TO BEARING BRACKET
95
NUT
101
LEVER CLUTCH, 1924 FROM TRANSMISSION 4 K.120 GP
105
BALL PIVOT CLUTCH ACTUATION,4 601609
109
NUT , Replaced By: N308675014000
113
RING AS REQUIRED 3.0 MM
117
THREADED PIN STOP LIGHT SWITCH
121
NUT , Replaced By: N308675012000
121
NUT , Replaced By: N000936012005
124
SPACER RING PEDAL TO BEARING BRACKET
128
SCREW CROSS MEMBER TO FRAME
128
SCREW LEVER TO RELEASE SHAFT
132
LOCK WASHER , Replaced By: N912004010102
136
NUT BRACKET TO RETARDER
224
ROD
229
ROD , 1924 FROM TRANSMISSION 4 K.120 GP
232
NUT , 1924 FROM TRANSMISSION 4 K.120 GP
232
NUT
236
TURNBUCKLE ,5 091743
240
NUT , Replaced By: N308675014000
248
NUT
252
BALL SOCKET
256
SECURING CLIP CLUTCH SLAVE CYLINDER TO LEVER,4 601609
264
LEVER CLUTCH OPERATION, 1924 FROM TRANSMISSION 4 K.120 GP
268
BALL PIVOT CLUTCH ACTUATION,4 601609
268
BALL PIVOT RELEASE YOKE
272
SEAL HOLDER ,D 357728
276
SEAL RING LEVER TO RELEASE SHAFT,5 285575
280
SCREW STRAP TO BRACKET
284
NUT BRACKET TO RETARDER
296
PULL ROD BRAKE PEDAL, 1924 FROM TRANSMISSION 4 K.120 GP
296
PULL ROD
300
YOKE PULL ROD TO LEVER
304
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
308
PIN , 385.068,069,FOR USE WITH MERCEDES-BENZ CAB
312
WASHER 10,5 DIN 433. WASHER , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
316
COTTER PIN , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
324
YOKE PULL ROD TO PEDAL AND TO BRAKE VALVE,D 357728 1924 FROM TRANSMISSION 4 K.120 GP
328
NUT SPRING BOLT
328
NUT BRACKET TO RETARDER
332
PIN PULL ROD TO BRAKE LEVER,REAR AXLE
336
COTTER PIN ENGINE CONTROL
340
WASHER SUPPORT TO FRAME,D 127794
348
BRACKET BRAKE PEDAL RELEASE SPRING,D 357728 1924 FROM TRANSMISSION 4 K.120 GP
368
SCREW AIR DUCT TO CAB
372
WASHER TRAILER PLUG SOCKET TO BRACKET
376
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
376
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
380
SPRING BRAKE PEDAL RESET
999
SHACKLE , Replaced By: A0019978390
999
CLAMP , Replaced By: N916016020201
999
RING , Replaced By: A3039910345
999
PEDAL PLATE
999
WASHER OPERATING VALVE TO SIDE MEMBER SHELL
999
BEARING BRACKET CLUTCH AND BRAKE
999
LEVER CLUTCH PEDAL, ON L FROM IDENT NO. 008464 ALSO INSTALLED ON 008448-008455
999
LEVER , Replaced By: A3502937110
999
BEARING TUBE
999
PEDAL , Replaced By: A3502907016
999
BALL PIVOT RELEASE YOKE
999
PEDAL
999
WASHER , Replaced By: A6202540176
999
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
999
NUT LEVER TO SHIFTING SHAFT
999
PIN , Replaced By: A3529910107
999
LOCK WASHER RAIL TO BATTERY SUPPORT
