Поз.
Артикул
Описание
4
CONNECTOR
8
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
12
LINE FROM AIR COMPRESSOR TO FITTING 15X1,5 MM,681096
12
LINE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3504209728
12
LINE FROM AIR COMPRESSOR TO FITTING 15X1,5 MM,600893681095
16
UNION NUT LINE CONNECTION
16
UNION NUT BUTT SCREW CONNECTION
20
GLAND LINE CONNECTION
24
CONNECTION FITTING HIGH PRESSURE LINE TO STEERING
28
SEAL RING , Replaced By: N007603012121
32
LINE FROM FITTING TO FITTING,665871
32
LINE FROM FITTING TO FITTING,665870
36
UNION NUT LINE CONNECTION
36
UNION NUT BUTT SCREW CONNECTION
40
GLAND LINE CONNECTION
44
LINE FROM DOUBLE FITTING TO PRESSURE REGULATOR 15X1.5 MM,681096
44
LINE FROM FITTING TO PRESSURE REGULATOR,665870
48
UNION NUT LINE CONNECTION
48
UNION NUT BUTT SCREW CONNECTION
52
GLAND LINE CONNECTION
56
CLAMP , Replaced By: A3609950210
60
SCREW CAP TO BRACKET
64
WASHER PLUG SOCKET TO BRACKET
68
NUT PUMP TO BRACKET
72
BRACKET CABLE TO TRANSMISSION
76
BRACKET BACK-UP LIGHT SWITCH BRANCH-OFF TO TRANSMISSION
80
BRACKET OIL LINE
84
CLAMP , Replaced By: A3129952420
88
CLAMP DELIVERY AND SUCTION LINES TO FRAME 12/15
88
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
92
SCREW METAL SPRING BELLOWS TO WEB
96
LOCK WASHER FITTING TO BRACKET
100
NUT BRACKET TO SIDE MEMBER
104
SCREW CABLE TO ALTERNATOR
108
WASHER PLUG SOCKET TO BRACKET
112
NUT PUMP TO BRACKET
116
SCREW BRACKET TO SIDE MEMBER
120
WASHER PLUG SOCKET TO BRACKET
999
GUIDE , Replaced By: N071752014000
999
CUPTO 008 420 97 18, 008 420 90 18, BOSCH
999
COVER SUPPLY, RED "WABCO"
999
COVER BRAKE,YELLOW "WABCO"
999
REPAIR KIT DIAPHRAGM PART BOSCH,209
999
REPAIR KIT CONTROL VALVE TO 002 431 28 05
999
REPAIR KIT TRISTOP CYLINDER TO 008 420 95 18, 008 420 97 18, BOSCH
999
REPAIR KITTO 384 430 76 09
999
REPAIR KIT SEAL RING BOSCH,209
999
DIAPHRAGMBOSCH, Replaced By: A0004314028
999
SPRINGTO 001 431 83 05
999
REPAIR KITTO 384 430 76 09
999
REPAIR KIT BRAKE LINE COUPLING "WABCO"
