Поз.
Артикул
Описание
441
MOUNTING (RUBBER BUFFER)
466
CONSOLE
476
SCREW BATTERY CASE TO SIDE MEMBER
481
WASHER CONSOLE TO CONSOLE
486
LOCK WASHER SUPPORT TO SIDE MEMBER
491
NUT BRACKET TO SIDE MEMBER
521
BRACKET COMPRESSED AIR LINES
526
SCREW , Replaced By: N304017010002
531
WASHER GROUND CABLE
536
NUT , Replaced By: N910113010003
541
MOUNTING
546
SCREW CONSOLE TO BRACKET M 12X1.5X25,20 L
551
SCREW , Replaced By: N304017010002
556
LOCK WASHER , Replaced By: N912004010102
561
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
566
WASHER A. WASHER BRACKET TO LEFT SIDE MEMBER
571
SHOCK ABSORBERFICHTEL & SACHS
571
SHOCK ABSORBER
576
RUBBER MOUNTING ,4 330046
581
BUSHINGFICHTEL&SACHS
586
SPRING BUSHING
591
SCREW , Replaced By: N308676012016
591
SCREW , Replaced By: N308676012018
601
WASHER SUPPORT TO FRAME,D 127794
606
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
611
HEX. NUT. NUT FUEL TANK TO CONSOLE,167609
636
SCREW , Replaced By: N304017010002
641
WASHER A. WASHER BRACKET TO LEFT SIDE MEMBER
646
LOCK WASHER , Replaced By: N912004010102
651
NUT BRACKET TO RETARDER
656
MOUNTING
661
SCREW , Replaced By: N304017010040
666
LOCK WASHER , Replaced By: N912004010102
671
WASHER A. WASHER BRACKET TO LEFT SIDE MEMBER
676
SHIM BRACKET TO FRAME
681
NUT BRACKET TO RETARDER
686
SPRING
691
SPRINGNO.1
696
SPRINGNO.2
701
SPRING510 MM
706
SPRINGNO.4
711
SPRING240 MM
716
SPRING BOLT
721
NUT LEVER TO SHIFTING SHAFT
726
CONSOLE CAB
731
PLATE
738
SCREW WATER SEPARATOR
741
SCREW STRAP TO BRACKET
746
LOCK WASHER , Replaced By: N912004010102
751
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
