Поз.
Артикул
Описание
267
PRESSURE REGULATOR , Replaced By: A0024314906
267
PRESSURE REGULATOR , Replaced By: A0024318306
267
PRESSURE REGULATOR , Replaced By: A0024314906
273
REPAIR KIT VALVE KIT WABCO,5 148812
273
REPAIR KITTO 001 431 98 06
273
REPAIR KITTO 001 431 12 06, KNORR 3200
273
REPAIR KIT , Replaced By: A0004301107
282
ELBOW FITTING AT PRESSURE REGULATOR
282
ELBOW FITTING PRESSURE REGULATOR,CONNECTION "1",A 069205
285
O-RING CHECK VALVE TO AIR RESERVOIR
288
THRUST RING CHECK VALVE TO AIR RESERVOIR
288
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
291
NUT AIR RESERVOIR,CONNECTIONS: "14,21,35"
292
SCREW PRESSURE REGULATOR TO BRACKET M 8X75
293
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
337
BRAKE VALVE SERVICE BRAKE KNORR
337
BRAKE VALVE , Replaced By: A3454317005
337
BRAKE VALVE (SERVICE BRAKE VALVE) KNORR
337
BRAKE VALVE SERVICE BRAKE WABCO
337
BRAKE VALVE (SERVICE BRAKE VALVE) WABCO
340
LOCKTO 345 431 70 05
340
LOCK RING
340
LOCK , Replaced By: N000472047001
340
LOCK RINGTO 345 431 71 05
340
LOCK , Replaced By: N000984038000
340
LOCK RINGTO 345 431 71 05
340
LOCK , Replaced By: N000472045000
340
LOCK RING PLANETARY CARRIER
340
LOCK , Replaced By: N000472060000
343
SPRINGTO 001 431 83 05
343
SPRINGTO 345 431 70 05
346
SPRINGTO 345 431 71 05
346
SPRINGTO 345 431 70 05
349
FILLER RINGTO 001 431 83 05,WABCO
352
BREATHER PIPETO 001 431 83 05,WABCO
355
PISTONTO 345 431 71 05
355
PISTONTO 001 431 83 05,WABCO
355
PISTONTO 002 431 27 05
355
PISTONTO 002 431 27 05
355
PISTONTO 345 431 70 05
358
REPAIR KIT LARGE SCOPE TO 345 431 70 05
358
REPAIR KIT , Replaced By: A0004304206
358
REPAIR KIT SMALL SCOPE TO 345 431 70 05
358
REPAIR KIT SMALL SCOPE TO 345 431 71 05
358
REPAIR KITKNORR
358
REPAIR KIT , Replaced By: A0014300460
424
NUT , Replaced By: N913004008001
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
999
TEST CONNECTION
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
PINTO 345 430 75 81
999
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
999
HANDLETO 345 430 75 81
999
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
999
BRACKET LEFT,DIAPHRAGM CYLINDER
999
BRACKET RIGHT,DIAPHRAGM CYLINDER
999
LINE FROM PRESSURE REGULATOR TO FITTING, NOT USED
999
T-FITTING RELAY VALVE,CONNECTION "1",A 072935
999
ELBOW FITTING DISTRIBUTOR,CONNECTION: "3"
999
SCREW , Replaced By: N304017008034
999
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
999
HOLLOW SCREW LINE TO OIL RADIATOR
