Поз.
Артикул
Описание
7
LINE FROM DIFFERENTIAL LOCK T-FITTING TO REAR AXLE
14
UNION NUT
21
GLAND , Replaced By: A0019901667
28
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
35
LINE FROM FITTING TO FITTING
35
LINE FROM FITTING TO FITTING
35
LINE FROM FITTING TO FITTING
42
UNION NUT
48
GLAND , Replaced By: A0019901667
56
LINE FROM DOUBLE FITTING TO THREE-WAY VALVE
63
UNION NUT
70
GLAND , Replaced By: A0019901667
77
VALVE , Replaced By: A0039971736
77
VALVE , Replaced By: A0029975836
84
REPAIR KITTO 003 997 14 36,WABCO 472 123 19 80
84
REPAIR KIT , Replaced By: A0024302260
84
REPAIR KITTO 003 997 14 36,WABCO 472 123 19 80
91
SCREW-IN FITTING LINE CONNECTION
98
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
105
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
122
SEAL RING
129
BRACKET VALVE
136
SCREW STEERING SHAFT BEARING TO CAB M 8X20
136
SCREW VALVE TO BRACKET
136
SCREW VALVE TO BRACKET
136
SCREW VALVE TO BRACKET
143
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
150
NUT TAIL LAMP TO BRACKET
157
BRACKET FUEL LINES
164
SCREW LICENSE PLATE TO BRACKET
164
SCREW FUEL LINE TO BRACKET
171
WASHER , Replaced By: N009021006208
178
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
184
NUT CLAMP TO BRACKET
191
CLAMP ,K 147121, Replaced By: N000000000319
191
CLAMP , Replaced By: N916016008200
198
BRACKET FUEL LINES
205
SCREW FUEL LINE TO BRACKET
212
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
219
NUT CLAMP TO BRACKET
226
CLAMP ,K 147121, Replaced By: N000000000319
226
CLAMP , Replaced By: N916016008200
233
BRACKET LINE MOUNTING
240
SCREW STEERING SHAFT BEARING TO CAB M 8X20
247
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
254
NUT TAIL LAMP TO BRACKET
261
CLAMP LINE MOUNTING
268
SCREWM 6X12
268
SCREW CLAMP TO BRACKET
275
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
282
NUT CLAMP TO BRACKET
290
HOSE FROM THREE-WAY VALVE TO COMPRESSED AIR CYLINDER
290
HOSE FROM THREE-WAY VALVE TO COMPRESSED AIR CYLINDER
297
UNION NUT LINE CONNECTION
304
GLAND LINE CONNECTION
311
SCREW-IN FITTING LINE CONNECTION
318
SEAL RING
999
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
999
GROMMET3.0 MM
999
EXPANSION PLUG TO PLUG THE FREE BORES IN INSTRUMENT PANEL
999
PLUG TO PLUG THE FREE HOLES FOR TELL-TALE LAMP
999
PIN BUSHING HOUSING BIPOLAR
999
PIN BUSHING , Replaced By: A0025457926
999
PIN BUSHING HOUSING 3-POLE
999
PLUG TO PLUG THE FREE HOLES IN INSTRUMENT PANEL, 344.030-033,036-038.040,041,058 FROM CHASSIS 652015
999
PIN BUSHING HOUSING 10-POLE
999
WASHER IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: 360 990 18 40
999
CABLE HARNESS FROM PUSHBUTTON SWITCH TO FRONT PLUG CONNECTION
999
CABLE HARNESS FROM FUSE BOX TO DIFFERENTIAL LOCK PUSH BUTTON SWITCH
999
CAP TO PLUG THE FREE BORES USED FOR SWITCHES IN INSTRUMENT PANEL,071184
999
SCREW BRACKET TO REAR AXLE TO 351 353 72 40
