Поз.
Артикул
Описание
4
PLATE ACCELERATOR PEDAL
4
PEDAL PLATE , Replaced By: A3523000802
8
GUARD PLATE ACCELERATOR PEDAL BEARING
12
BEARING TUBE ACCELERATOR PEDAL CONTROL,GB718835
12
BEARING TUBE ACCELERATOR PEDAL CONTROL
14
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
18
SCREW CLAMP TO BRACKET AND TO PIPE
22
LEVER , INAPPLICABLE TO SUPERCHARGING SYSTEMGB718835
28
ROD FROM CONTROL SHAFT TO INTERMEDIATE SHAFT
28
ROD , Replaced By: A3604301892
33
NUT BALL PIVOT TO LEVER
38
BALL SOCKET PULL ROD TO LEVER
38
BALL SOCKET , Replaced By: A0009912422
38
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
45
PLATE
50
PIN PEDAL TO CAB FLOOR
55
SAFETY PIN END PIECE TO CONTROL LEVER
60
ROD CONTROL
65
BEARING BRACKET
70
BUSHING
76
SHAFT
82
LEVER
88
ROD , Replaced By: A3604301992
88
ROD , Replaced By: A3604302092
96
NUT BALL PIVOT TO LEVER
102
BALL SOCKET PULL ROD TO LEVER
102
BALL SOCKET , Replaced By: A0009912422
108
KNOB WITH SPINDLE AND WIRE CABLE
108
KNOB , Replaced By: A3523001407
108
KNOB , Replaced By: A3523001407
114
TUBE , UP TO IDENT NO. 4 155516 ALSO INSTALLED ON 500001-521292
120
WIRE CABLE , UP TO IDENT NO. 4 155516 ALSO INSTALLED ON 500001-521292
120
WIRE CABLE , Replaced By: A3523000230
126
KNOB , FROM IDENT NO. 739256 ALSO INSTALLED ON:500001-599999 UP TO IDENT NO. 4 155516 ALSO INSTALLED ON 500001-521292
126
KNOB , Replaced By: A3523020201
126
KNOB , UP TO IDENT NO. 739255 EXCEPT FOR 500001-599999, Replaced By: A3523020201, +001A3523020308
132
WASHER , UP TO IDENT NO. 4 155516 ALSO INSTALLED ON 500001-521292
138
GUIDE , FROM IDENT NO. 739256 ALSO INSTALLED ON:500001-599999 UP TO IDENT NO. 4 155516 ALSO INSTALLED ON 500001-521292
138
GUIDE , Replaced By: A3523020308
138
GUIDE , UP TO IDENT NO. 739255 EXCEPT FOR 500001-599999, Replaced By: A3523020308, +001A3523020201
144
NUT , UP TO IDENT NO. 4 155516 ALSO INSTALLED ON 500001-521292
150
CLAMP
156
GROMMET WIRE CABLE TO MOUNTING CLAMP, FROM IDENT NO. 4 155517 ALSO INSTALLED ON:500001-599999
156
GROMMET WIRE CABLE TO MOUNTING CLAMP, FROM IDENT NO. 4 155517 ALSO INSTALLED ON:500001-599999
156
GROMMET , Replaced By: A3453027091
999
BALL PIVOT LEVER
999
SHIM CONTROL SHAFT BEARING TO FIRE WALL
999
COVERING ACCELERATOR PEDAL BEARING
999
BRACKET OIL LINE TO CRANKCASE
999
SCREW LICENSE PLATE TO BRACKET,4 300861
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
COTTER PIN CYLINDER TO BRACKET
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER BRACKET TO CROSS MEMBER
999
SCREW CONNECTOR
999
SCREW , Replaced By: N304017006034
999
SCREW , Replaced By: N304017008040
999
BALL PIVOT , Replaced By: A3129910120
999
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
SCREW BRACKET TO SIDE MEMBER
999
NUT
999
PULL ROD LOAD SENSOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
999
PULL ROD AT CONTROL LEVER, TO BE ADAPTED DURING ASSEMBLY
999
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
999
HEXALOBULAR BOLT. SCREW MANUAL PUMP BRACKET TO FENDER BRACKET
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
