Mercedes N304032005005 - Гайка M 5

OF 1617 355.098

27 AUTOMATIC TRANSMISSION - 001 CHASSIS PARTS W/ALLISON TRANSMISSION MT643 IL.3

Поз.
Артикул
Описание
1
A3525050501
RADIATOR SHUTTER
1
A3525050401
RADIATOR SHUTTER
1
A3525050301
RADIATOR SHUTTER
1
A3525050201
RADIATOR SHUTTER , Replaced By: A3525050401
1
A3525050101
RADIATOR SHUTTER , Replaced By: A3525050001
1
A3525050001
RADIATOR SHUTTER
3
A0005054901
RADIATOR SHUTTER
12
A0005050110
CABLE PULL
14
A0005050006
CLAMP
16
A0005051609
CHAIN630 MM
22
A3525040184
SHIM
23
N007513005308
TAPPING SCREW
25
A0005050582
HOSE1200 MM
28
A0009973781
GROMMET , UP TO CHASSIS 603580 ON SPECIAL REQUEST, SEPARATE BRAKE FLUID RESERVOIR FOR HYDRAULIC BRAKE
28
A0009972481
GROMMET CLUTCH LINE TO BRACKET
999
A0005050782
HOSE550 MM
999
A0005051909
CHAIN550 MM
999
A0009972581
GROMMET CLUTCH LINE TO BRACKET
999
A0009972681
GROMMETTO 341 540 82 10
999
A3525050110
CABLE PULL
999
N000084005106
SCREW CONTACTOR
999
N007981004279
SHEET METAL SCREW BRACKET TO WINDOW LEVEL GIRDER
999
N304032005002
NUT , Replaced By: N304032005005
999
N304032005005
NUT IN CASE OF SUBSEQUENT INSTALLATION
999
N912004005103
LOCK WASHER BRACKET TO STEERING COLUMN END
