Поз.
Артикул
Описание
1
AIR CLEANER
2
AIR CLEANER
3
AIR CLEANER
5
FILTER ELEMENT
6
FILTER ELEMENTTO 010 094 83 02
7
GASKET INSIDE
8
GASKET BOTTOM
9
GASKET OUTSIDE
11
GASKET OUTSIDE
12
GASKET
13
FILTER BOWL
15
SCREW
16
AIR CLEANER
17
AIR CLEANER
18
CONNECTION PIPE SOCKET
19
GASKET
20
BRACKET
30
COVER
32
AIR INTAKE PIPE
33
AIR INTAKE PIPE
34
AIR INTAKE PIPE
35
SUPPORT OIL BATH AIR CLEANER
999
FASTENER
999
BRACKET OIL BATH AIR CLEANER
999
SLEEVE INTAKE MUFFLER,OR AIR INTAKE PIPE,TO AIR CLEANER
999
GASKET TOP
999
WASHER
999
SNAP RING DIA., 128 MM
999
CLAMP FROM AIR CLEANER TO TRANSVERSE INTAKE PIPE, TO BE ADAPTED DURING ASSEMBLY
999
AIR CLEANER
999
AIR CLEANER
999
HOSE CLAMP FROM AIR CLEANER TO TRANSVERSE INTAKE PIPE, Replaced By: A0019951910
999
AIR CLEANER
999
BOOT OIL BATH AIR CLEANER
999
BOOT OIL BATH AIR CLEANER
999
AIR INTAKE PIPE FROM AIR INTAKE PIPE TO ENGINE, 6293954 697162
999
CLAMP HOSE 70-90X13 MM
999
WASHER
999
HEX. HEAD. SCREW FLANGE TO EXHAUST MANIFOLD
999
SCREW BRACKET TO FRAME
999
NUT STRAP TO SUPPORT,5 149419
999
HOSE 250 MM LONG FROM OIL BATH AIR CLEANER TO AIR INTAKE PIPE,CLEANER AIR
999
HOSE FROM OIL BATH AIR CLEANER TO INTAKE PIPE 110X128X120 MM, ORDER BY THE METER
999
LOCK WASHER FITTING TO BRACKET
999
CLAMP , Replaced By: N000000000674
999
CLAMP FROM AIR CLEANER TO HOT AIR INTAKE PIPE
999
CLAMP , Replaced By: A0059971490
999
CLAMP FROM AIR CLEANER TO TRANSVERSE INTAKE PIPE,5 158927
