Поз.
Артикул
Описание
405
SEALING RING. SEAL RING ENGINE BREATHING
420
HOSE FROM PRESSURE REGULATOR TO STOP VALVE, ORDER BY THE METER
425
HOSE PRESSURE REGULATOR ON INTAKE CASE, ORDER BY THE METER
430
HOSE FROM PRESSURE REGULATOR TO STOP VALVE, ORDER BY THE METER
445
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
445
CLAMP CABLE HARNESS MOUNTING
445
CLAMP , Replaced By: N916016010211
445
CLAMP , Replaced By: N000000001045
445
CLAMP , Replaced By: N916017011001
445
CLAMP , Replaced By: N000000000665
450
CLAMP HOSE TO FITTING AND TO OIL TANK
450
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
455
CLAMP25-40X13 MM
455
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
460
CENTRAL PART PRESSURE REGULATOR
465
T-FITTING PRESSURE REGULATOR ON GAS MIXER
485
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
490
HOLLOW SCREW HEATING CONNECTION
495
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
505
VALVE PRESSURE REGULATOR, IDLE SPEED
510
VALVE PRESSURE REGULATOR "1",077966
510
VALVE PRESSURE REGULATOR "1"
525
VALVE PRESSURE REGULATOR "2"
525
VALVE PRESSURE REGULATOR "2",077966
530
VALVE (3/2-WAY SOLENOID VALVE) EKS
530
VALVE , Replaced By: A0049975736
560
BRACKET PRESSURE REGULATOR
575
SCREW , Replaced By: N304017006049
585
NUT HEATING PIPE TO BRACKET
595
RUBBER BUFFER , Replaced By: A0009887511
595
BUFFER BRACKET TO PRESSURE REGULATOR
600
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
605
WASHER BRACKET TO CAB REAR PANEL
605
WASHER BRACKET TO LEFT SIDE MEMBER
615
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
620
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
625
FITTING LINE CONNECTION
630
SEAL RING 3/2-WAY VALVE
645
SCREW. UNION SCREW , Replaced By: A0009973734
645
SCREW. UNION SCREW LINE CONNECTION
999
NUT10 MM
999
SEAL CONE FRONT 10 MM
999
SEAL CONE REAR 10 MM
