Поз.
Артикул
Описание
5
SENDER UNIT JACKKNIFING ANGLE
5
8
SCREW , Replaced By: N304017006020
8
SCREW LICENSE PLATE TO BRACKET
11
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
14
NUT PUMP TO BRACKET
14
NUT , Replaced By: N913004006001
17
SCREW , Replaced By: N304017006016
17
SCREW PUMP TO BRACKET
20
NUT , Replaced By: N913004006001
20
NUT PUMP TO BRACKET
23
LEVER , Replaced By: A3575420342
26
SCREW SHIM TO LEAF SPRING
26
SCREW , Replaced By: N000912006175
26
SCREW , Replaced By: A0019907212
29
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
32
NUT PUMP TO BRACKET
32
NUT , Replaced By: N913004006001
35
BUFFER
35
BUFFER
38
NUT PUMP TO BRACKET
38
NUT , Replaced By: N913004006001
41
PIN RUBBER BUFFER TO PITMAN ARM
44
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
47
MOUNTING PLATE STEERING ANGLE SENDER UNIT BRACKET
50
SCREW VALVE TO BRACKET M 8X55
50
SCREW , Replaced By: N304017008043
53
WASHER , Replaced By: N000125008443
53
WASHER EXHAUST MUFFLER TO STRAP
56
NUT , Replaced By: N913004008001
59
BRACKET STEERING ANGLE SENDER UNIT, NOT USED
62
LEVER , Replaced By: A3575420342
65
BALL PIVOT LEVER
65
BALL PIVOT , Replaced By: A3129910120
68
SCREW , Replaced By: N000912006175
68
SCREW , Replaced By: A0019907212
68
SCREW SHIM TO LEAF SPRING
71
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
74
NUT PUMP TO BRACKET
74
NUT , Replaced By: N913004006001
77
OPERATING ROD JACKKNIFING ANGLE SENDER UNIT
80
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
999
CYLINDER GASKET KIT WEBER
999
CONTROL UNIT , Replaced By: A0015537302
999
CONTROL UNIT JACKKNIFING-ANGLE/DAMPING REGULATION
999
SWITCHTO 001 553 71 02
