Поз.
Артикул
Описание
115
GASKET1 MM
120
HOUSING THERMOSTAT
125
WASHER EXHAUST MUFFLER TO STRAP
125
WASHER , Replaced By: N000125008443
130
SCREW , Replaced By: N304017008030
130
SCREW PILLAR TO BRACKET AND TO FRONT PANEL
135
GASKET HEATING PIPE TO ENGINE
145
FLANGE (BLIND FLANGE)
150
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
155
SCREW CABLE HARNESS MOUNTING
155
SCREW BRACKET TO APPARATUS SUPPORT
155
SCREW , Replaced By: A0069909301
155
SCREW , Replaced By: N304017008023
160
GASKET COVER TO THERMOSTAT HOUSING,078816
160
GASKET COVER TO THERMOSTAT HOUSING, NOT USED
165
COVER THERMOSTAT HOUSING
167
SPRING WASHER LICENSE PLATE TO BRACKET
170
SCREW COVER TO THERMOSTAT HOUSING
173
SCREW BRACKET TO OIL FILLER PIPE BRACKET,D 200055
173
HEXAGON HEAD BOLT ELECTRONICS AT SUPPORT M6X30,V 207570
175
GASKET , Replaced By: A3522032680
175
GASKET DE-AERATION LINE TO HEATING LINE
210
THERMOSTAT ELEMENT
210
THERMOSTAT ELEMENT
210
THERMOSTAT ELEMENT , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 430461YEAR OF MANUFACTURE 1996, Replaced By: A0052032675
216
LINE
220
SEAL RING FUEL LINE TO FEED PUMP
225
SCREW PLUG FUEL TANK
225
SCREW PLUG , Replaced By: N007604014110
230
GASKET , Replaced By: A3522032680
230
GASKET DE-AERATION LINE TO HEATING LINE
235
LINE
238
PIPE ELBOW ,110173
245
SCREW 3/2-WAY VALVE TO BRACKET
245
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET M 8X95
245
SCREW , Replaced By: N304014008018
250
GASKET UPPER COOLING WATER LINE TO CYLINDER HEAD
255
WASHER , Replaced By: N000125008443
255
WASHER EXHAUST MUFFLER TO STRAP
260
SCREW DIFFERENTIAL CASE
260
SCREW FILTER BOWL TO FILTER HEAD M 8X90,841477 ONLY FOR USE WITH BOSCH DOUBLE FILTER
260
SCREW BRACKET TO CROSS MEMBER
265
GASKET COOLING WATER LINE TO WATER PUMP
270
LINE ,035018
275
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
280
SCREW SUPPORT TO CROSS MEMBER M 10X28
285
SCREW , Replaced By: A0089907401
285
SCREW , Replaced By: N304017008016
285
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
285
SCREW BRACKET TO SIDE MEMBER,K 168169
290
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
295
WASHER CLUTCH AND BRAKE PEDALS TO LEVER,4 282707
295
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
999
HOUSING
999
FLANGE HEATING CONNECTION LOCK,5 301949
999
LINE UPPER COOLING WATER LINE
999
PIPE ELBOW ,110172, Replaced By: A3602001018, +002N000931008131
999
LINE ,035017, Replaced By: A3602001652, +001N000933008030, +001N007349008002
999
THERMOSTAT ELEMENT , NOT USED, Replaced By: A0032032975
999
THERMOSTAT ELEMENT , 314.9 259272 352.9 437435, Replaced By: A0032033175, +001A3522032280
999
THERMOSTAT ELEMENT ,078816, Replaced By: A0032032875, +001A3522032280
999
SEAL , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0002018019
