Поз.
Артикул
Описание
5
TRANSVERSE CONTROL ARM
5
TRANSVERSE CONTROL ARM
8
PIN CONTROL ARM TO FRONT AXLE,C 073141
11
NUT LEVER TO TORSION BAR
14
COTTER PIN PISTON ROD TO LIFTING ARM
17
THRUST WASHER PIN TO STRUT,C 073141
20
HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X50
23
HEXAGON HEAD BOLT. SCREW MOUNTING PARTS M16 X 1.5 X 100
26
NUT FIFTH WHEEL COUPLING TO MOUNTING PLATE M16X1.5
29
THRUST ARM
29
THRUST ARM
30
30
31
REPAIR KIT DRIVE FLANGE TO A 628 333 19 05
31
REPAIR KIT THRUST ARM TO BEARING BODY
32
SCREW MOUNTING PARTS M16 X 1.5 X 110
32
HEXAGON HEAD BOLT MOUNTING PLATE TO SIDE MEMBER AND TO AUXILIARY FRAME M16X1.5X70
32
SCREW FIFTH WHEEL COUPLING TO MOUNTING PLATE M 16X1.5X55, IN CONJUNCTION WITH CODE: KQJ5 IN CONJUNCTION WITH CODE: 9J5Q
38
NUT FIFTH WHEEL COUPLING TO MOUNTING PLATE M16X1.5
41
THRUST WASHER PIN TO STRUT,C 073141
44
HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X50
51
RS CONTROL ARM TO A6343300107/ 0211/0411 LEMFORDER
