Поз.
Артикул
Описание
6
ALTERNATOR , Replaced By: A0071542802, +001A0001559115, +001A4221550118
46
GREASE NIPPLETO 002 154 85 02
46
GREASE NIPPLE
46
GREASE NIPPLETO 005 154 62 02
56
COVERTO 005 154 62 02,049383
56
COVERTO 004 154 79 02
61
SEAL RING , NOT USED
66
SPACER RINGTO 004 154 79 02,004 154 82 02
76
BEARING BODYTO 004 154 79 02
96
GROOVED BALL BEARING LEFT ALTERNATOR MOUNTING,061991
96
GROOVED BALL BEARING DRIVE END BEARING TO 002 154 85 02
96
BALL BEARING
96
GROOVED BALL BEARING DRIVE END BEARING 005 154 45 02/84 02
126
CYLINDR. ROLLER BEARING
126
CYLINDR. ROLLER BEARING ,061991
131
SEAL RING ,061991
176
SPRING WASHER SHIFTING YOKE BEARING
186
NUT SPRING SHACKLE TO SPRING REAR BRACKET
196
WASHER
206
BUSHINGTO 004 154 79 02,004 154 82 02
216
CARBON BRUSH SET ,600808
246
CONNECTORTO 004 154 79 02,004 154 82 02
251
CONNECTOR
251
CONNECTORTO 004 154 13 02,049382
256
ELECTRIC CABLETO 004 154 79 02
256
ELECTRIC CABLETO 004 154 79 02,004 154 82 02
266
RECTIFIERTO 004 154 79 02
266
RECTIFIERTO 009 154 08 02,008 154 78 02
266
RECTIFIER , Replaced By: A0001549716
306
DIODE EXCITER TO 004 154 79 02
306
DIODETO 005 154 01 02
306
DIODETO 005 154 01 02
326
CONDENSER
326
CONDENSER ,061991
326
CONDENSER ,054430
336
GASKETTO 004 154 79 02
376
CONTACT RAILTO 004 154 79 02
416
BOOT HEATER PLUGS
416
BOOT POS. CABLE
446
PULLEY
446
PULLEYTO 004 154 83 02,005 154 62 02
456
FAN ,600808
456
FAN005 154 62 02,004 154 83 02
999
PIPE SOCKET , Replaced By: A0001540365
999
PIPE SOCKET , Replaced By: A0001540365
999
PIPE SOCKET , Replaced By: A4031540365
999
PIPE SOCKET , Replaced By: A4071540165
999
GASKET
999
SPRINGTO 004 154 75 02
999
CONNECTOR , Replaced By: A0001541918
999
SPRING , Replaced By: A0001541193
999
RECTIFIER , Replaced By: A0001544816
999
SPRING
999
CARBON BRUSH SET , Replaced By: A0001547214
999
BEARING BODY , Replaced By: A0001550101
999
PULLEY , Replaced By: A0001555515
999
FAN WITH PULLEY
999
FAN ALTERNATOR
999
FANTO 005 154 34 02,007 154 27 02/07 02,208848/91
999
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
999
BOOT , Replaced By: A0005463335
999
REPAIR KIT , Replaced By: A0001500672
999
LOCK WASHER
999
SCREW REGULATOR MOUNTING TO 009 154 07 02
999
PULLEY , Replaced By: A0011551015
999
FANTO 011 154 50 02
999
CONDENSER THREE-PHASE ALTERNATOR INTERFERENCE SUPPRESSION
999
CONDENSERTO 002 154 85 01
999
PLUG SOCKET , Replaced By: A0005453726
999
SNAP RING
999
SEAL RINGTO 002 154 85 02
999
ALTERNATOR ,049383
999
ALTERNATOR , Replaced By: A0041547902
999
V-BELT , Replaced By: A0039970292
999
V-BELT
999
V-BELT FAN DRIVE,D 180260
999
V-BELT , Replaced By: A0049979292
999
ALTERNATOR , Replaced By: A0041548302
999
ALTERNATOR ,049383, Replaced By: A0051546202, +001A0001552415
999
ALTERNATOR ,049383, Replaced By: A0051544502
999
PLUG , Replaced By: A0015457726
999
PLUG 4-POLE,5 064562
999
ALTERNATOR , Replaced By: A0071542602
999
ALTERNATOR , NOT USED
999
ALTERNATOR , Replaced By: A0061548602, +001A0001555515
999
ALTERNATOR , Replaced By: A0041548302
999
ALTERNATOR , Replaced By: A0051548402, +001A4221550018
999
ALTERNATOR , Replaced By: A0111545002
999
CLAMPING PIECE TIGHTENER PULLEY TO LEVER
999
SCREENING PLATE , Replaced By: A3521500675
999
CLAMPING BOLT (CLAMPING BOLT)
999
NUT ALTERNATOR
999
BUSHING
999
ELECTRIC CABLE , Replaced By: A3835400141
999
BRACKET
999
BRACKET , Replaced By: A3601501573
999
GROUND STRAP
999
COVER
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER SUPPORT TO FRAME,D 127794
999
STUD
999
NUT FUEL TANK TO SUPPORT
999
SCREW AIR RESERVOIR CONSOLE TO SIDE MEMBER
999
SCREW CLAMPING BOLT TO ALTERNATOR
999
GREASE CUP , Replaced By: A0009971988
999
SCREW APPARATUS PLATE TO CAB,K 062140
