Поз.
Артикул
Описание
4
ENGINE SUPPORT REAR LEFT
7
RUBBER MOUNTING REAR
7
RUBBER MOUNTING , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 356313, Replaced By: A6452400218
7
RUBBER MOUNTING , Replaced By: A6172400518
7
RUBBER MOUNTING REAR
7
RUBBER MOUNTING , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 356313, Replaced By: A6452400018
7
RUBBER MOUNTING , Replaced By: A6172400418
7
RUBBER MOUNTING REAR
7
RUBBER MOUNTING , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 356313, Replaced By: A6452400118
7
RUBBER MOUNTING , Replaced By: A6172400318
9
CONSOLE ,939779
11
WASHER
13
LOCK WASHER FITTING TO BRACKET
15
SCREW CONSOLE TO SIDE MEMBER
17
LOCK WASHERROCKINGER TYP 59 G140,59 G150
19
SCREW BEARING BRACKET TO FRAME
21
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
21
CLUTCH PRESSURE PLATE , Replaced By: A0022507704
24
HOUSING
27
CLAMP RELEASE FLANGE TO RELEASE LEVER
29
PRESSURE PLATE
32
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
34
SCREW STEERING COLUMN TO CAB
36
SPACER RING
39
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
41
SCREW , Replaced By: N000912008062
45
RELEASE LEVER CLUTCH ACTUATION
49
BUSHING RELEASE LEVER
51
TORS. VIBRATION ABSORBER
53
SPINDLE FOR BEDDING THE LEVERS IN CLUTCH PRESSURE PLATE
55
SPINDLE FOR BEDDING THE LEVERS IN BRACKETS
57
BRACKET RELEASE LEVER
59
LOCK PLATE RELEASE LEVER TO SHAFT
61
FLANGE CLUTCH RELEASE
63
SPRING RELEASE LEVER
63
SPRING , Replaced By: A0002522927
65
PRESSURE SPRING
69
LEAF SPRING FOR BRACKETS
71
LOCK WASHER BRACKET TO STEERING COLUMN END
73
SCREW RELEASE LEVER,BRACKET
75
NUT FOR BRACKETS
77
LOCK FOR BRACKETS
82
CLUTCH DISC
82
CLUTCH DISC ASBESTOS-FREE LINING
84
LEAF SPRING
84
LEAF SPRING , REBORE HOLE IN SUPPORTING PLATE FROM 5.2MM TO 6.2MM, Replaced By: A0002523919, +002A0002523975
84
LEAF SPRING , Replaced By: A0002523319
86
RIVET LEAF SPRING TO CLUTCH DISC
86
RIVET LEAF SPRING TO CLUTCH DISC 5X6 MM
86
RIVET , Replaced By: A0002522075
88
CLUTCH LINING
88
CLUTCH LINING , Replaced By: A0012522010
88
CLUTCH LINING ASBESTOS-FREE
88
CLUTCH LINING , Replaced By: A0022520010
88
CLUTCH LINING , Replaced By: A0012528310
90
RIVET LINING WITH CLUTCH DISC
90
RIVET , Replaced By: A0002524875
90
RIVET , Replaced By: A0002524675
90
RIVET , Replaced By: A0002523775
90
RIVET , Replaced By: A0002523375
92
RIVET LINING WITH CLUTCH DISC
92
RIVET , Replaced By: A0002524875
999
TORS. VIBRATION ABSORBER
999
SPACER RING
999
CLAMP , Replaced By: A0002523227
999
SHIM
999
SHIM
999
RIVET LINING WITH CLUTCH DISC AND INTERMEDIATE SPRING,4 372223
999
PRESSURE PLATE
999
HOUSING CLUTCH PRESSURE PLATE, FROM IDENT NO. 650281 EXCEPTO SEE FOOTNOTE 9
999
RELEASE LEVER , Replaced By: A0002524613, +006A0002520614, +006A0002522816, +012A0019921401, +006N006799007003
999
CLUTCH LINING ASBESTOS-FREE,4 372223
999
CLUTCH LINING , Replaced By: A0002527510
999
SHIFTING CYLINDER , Replaced By: A0002606463
999
OIL PUMP , Replaced By: A0002601090
999
VALVE , Replaced By: A0002608057
999
TRANSMISSION CASE COVER , Replaced By: A0002610418, +001A0002610418, +001A0002614880
999
COVERING
999
CENTERING RING
999
SNAP RING DRIVE SHAFT
999
COVERING DRIVE SHAFT
999
DRIVE SHAFT
999
DRIVE SHAFT
999
LEVER
999
OIL GUIDE RING , Replaced By: A0002640163
999
BEARING BRACKET
999
OIL GUIDE RING , Replaced By: A0002640263
999
NOZZLE OIL DISTRIBUTOR BLOCK TO 000 264 55 02
999
OIL GUIDE RING
999
OIL BAFFLE DRIVE SHAFT
999
SCREW , Replaced By: A0002641871
999
THRUST WASHER AS REQUIRED 4.40 MM
999
PIN
999
THRUST WASHER AS REQUIRED 4.00 MM
999
OIL PIPE
999
SCREW P.T.O. HOUSING TO BELL HOUSING
999
REPAIR KITHERION,94171034/0711/24V,94172034/0711
999
EXPANSION PLUG OIL DISTRIBUTOR BLOCK TO 000 264 59 02
999
CLUTCH DISC
999
CLUTCH DISC ASBESTOS-FREE LINING, FROM IDENT NO. 764485 ALSO INSTALLED ON 500001-599999
999
CLUTCH PRESSURE PLATE
999
REPAIR KITTO 001 997 34 36,002 997 58 36,
999
REPAIR KIT , Replaced By: A0012608357
999
SEAL RING HOLLOW SHAFT,INSIDE
999
CLUTCH DISC ASBESTOS-FREE LINING
999
LOOM TIE
999
SEAL RING CASE COVER
999
SEAL RING , Replaced By: A0089973847
999
SPRING LOCK RELEASE COLLAR TO RELEASE YOKE
999
WASHER AS REQUIRED 1.00 MM
999
RELEASE YOKE
999
HOSE RELEASE BEARING LUBRICATION 170 MM
999
CONNECTOR
999
BUSHING TOP
999
BUSHING RELEASE SHAFT,BOTTOM
999
P.T.O.N 70-1 C
999
SPACER WASHER AS REQUIRED 0.30 MM
999
SPACER WASHER , Replaced By: A3432610752, +001A3432610652
999
COVER PLATE
999
SPACER WASHER RELEASE SHAFT,BOTTOM
999
WASHER LEVER TO RELEASE SHAFT, WITH L.H.D.FROM IDENT NO. 602167,WITH R.H.D.FROM IDENT NO. 601938
999
LOCK WASHER , Replaced By: N912006012000
999
BUSHING TOP
999
BUSHING RELEASE SHAFT,BOTTOM 24X27 MM
999
RUBBER MOUNTING , Replaced By: A3872400218
999
CLAMP LINE MOUNTING
999
SHIFT LEVER P.T.O.
999
ENGINE SUPPORT REAR RIGHT
999
RELEASE BEARING
999
RELEASE LEVER
999
HOUSING CLUTCH,841164
999
RELEASE COLLAR
999
RELEASE COLLAR
999
TRANSMISSIONS6-90V
999
TRANSMISSION , Replaced By: A3632607501
999
TRANSMISSIONS 6-90 V MIT NMV 110/1
999
BRACKET SHIFTING CYLINDER
999
GUIDE CABLE GUIDE
999
BEARING
999
BEARING
999
BEARING
999
CABLE CLUTCH OPERATION
999
BRACKET CABLE
999
CABLE CLUTCH OPERATION
999
BRACKET
999
WASHER LEVER TO CONSOLE
999
INTERMEDIATE PIECE
999
BRACKET THROTTLE HOUSING,LEFT
999
BRACKET RIGHT
999
BRACKET LEFT
999
BRACKET RIGHT
999
BALL SOCKET RELEASE COLLAR
999
BALL SOCKET RELEASE COLLAR
999
COVER
999
SHAFT , Replaced By: A3635860025
999
RUBBER MOUNTING , Replaced By: A3872400218
999
EXPANSION PLUG P.T.O. HOUSING
999
BUSHING CABLE GUIDE
999
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
HEXALOBULAR BOLT. SCREWM 8X45
999
COTTER PINROCKINGER TYP 260 G140
999
SPRING WASHER STEERING COLUMN BRACKET TO CAB
999
EXPANSION PLUG
999
SCREW , Replaced By: N000000001448
999
SCREW EXHAUST PIPE TO BRACKET
999
NUT BALL PIVOT TO LEVER
999
FELT RING
999
SCREW NMV FOLLOWER TO CLUTCH PRESSURE PLATE
999
SEAL RING VALVE TO VALVE,K 025179
999
SCREW PLUG
999
HOLLOW SCREW
999
LOCK RING TRANSMISSION CASE TOP COVER,4 1471924 147193 SEE UNIT MICROFICHE,MODEL: 712.0014 147193 SEE UNIT MICROFICHE,MODEL: 712.001
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
COMBINATION BOLT
