Поз.
Артикул
Описание
5
FRONT PLATE (CONTROL LEVER)
8
LEVER (CONTROL LEVER)
11
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
14
COVERING , Replaced By: A6153010088
17
LOCK PLATE
20
SCREWM 6X12
23
WASHER PLUG SOCKET TO BRACKET
26
LEVER , Replaced By: A3643009725
26
LEVER (SHUT-OFF LEVER)
29
BUSHING ,950252
32
SEAL RING
35
EXPANSION PLUG SHUT-OFF LEVER
38
PIN
41
CYLINDRICAL PIN
44
GREASE NIPPLE
47
SCREW CLUTCH TO FLYWHEEL M8X18,4 188090-4 277323
50
WASHER TRAILER PLUG SOCKET TO BRACKET
53
SPRING RELEASE SPRING, UP TO CHASSIS 556499 EXCEPT FOR 553795,555902,556120
56
KNOB ENGINE SHUT-OFF
59
KNOB , FROM CHASSIS: 023 009981 072 004629 073 001470
62
SPINDLE ENGINE SHUT-OFF
65
DAMPING RING
68
WASHER , UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
71
BUSHING KNOB WITH SPINDLE TO BRACKET
74
RUBBER RING KNOB WITH SPINDLE TO BRACKET,C 086993
77
COVER PLATE KNOB WITH SPINDLE TO BRACKET,C 084110
80
TOOTHED WASHER SENDER UNIT TO BRACKET
83
NUT BRACKET TO SIDE MEMBER
86
WASHER PRECISION CONTROL
89
LOCK PLATE
92
END PIECE PRECISION CONTROL, UP TO IDENT NO. 039909 EXCEPT FOR 301.225 WITH COUNTRY CODE 837 UP TO IDENT NO. 039676 301.265 WITH COUNTRY CODE 837 UP TO IDENT NO. 039438
95
PIN END PIECE TO CONTROL LEVER 8X12 MM
98
WASHER LINE TO CROSS AND SIDE MEMBERS
101
COTTER PIN ROLLER TO LEVER
104
PULL ROD FROM CONTROL LEVER TO SHUT-OFF LEVER
107
JOINT ROD TO LEVER
107
ANGLE JOINT ROD TO LEVER
110
WASHER FUSE TO FUSE BOX
113
NUT TACHOGRAPH TO BRACKET
