Поз.
Артикул
Описание
1
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
1
CLUTCH PRESSURE PLATE , Replaced By: A0032502504
3
HOUSING
5
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
5
SPRING SUSPENDED BELOW LEAF SPRING
6
CLAMP , Replaced By: A0002523227
7
PRESSURE PLATE
12
RELEASE LEVER CLUTCH ACTUATION
14
SPINDLE FOR BEDDING THE LEVERS IN CLUTCH PRESSURE PLATE
15
SPINDLE FOR BEDDING THE LEVERS IN BRACKETS
15
SPINDLE , Replaced By: A0002522816, +001A1249945241
16
ROLLER FOR BEDDING THE LEVERS IN BRACKETS
17
BRACKET RELEASE LEVER
18
LOCK PLATE RELEASE LEVER TO SHAFT
18
LOCK PLATE LEVER TO BRACKET
27
FLANGE
27
FLANGE , Replaced By: A0002522145
29
SPRING SUSPENDED BELOW LEAF SPRING
29
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
29
SPRING , Replaced By: A0002523227
30
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.75 MM
31
PRESSURE SPRING SPRING STEEL WIRE DIA., 4.00 MM
32
LEAF SPRING THIGH SPRING SUSPENDED BELOW LEAF SPRING
32
LEAF SPRING THIGH SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
33
NUT FOR BRACKETS
33
NUT , Replaced By: A0002523072
34
LOCK FOR BRACKETS
36
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING
36
SCREW RELEASE LEVER,BRACKET
40
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
41
SCREW , Replaced By: N304017010050
41
SCREW , Replaced By: N304017010055
47
CLUTCH DISC ASBESTOS-FREE LINING
47
CLUTCH DISC ASBESTOS-FREE LINING, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
47
CLUTCH DISC , Replaced By: A0022509803
47
CLUTCH DISC , Replaced By: A0052506403
47
CLUTCH DISC , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0062504603
47
CLUTCH DISC
47
CLUTCH DISC , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0062504503
47
CLUTCH DISC , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0072500803
47
CLUTCH DISC
49
LEAF SPRING , REBORE HOLE IN SUPPORTING PLATE FROM 5.2MM TO 6.2MM, Replaced By: A0002523819, +002A0002523975
49
LEAF SPRING
51
RIVET , Replaced By: A0002522075
51
RIVET LEAF SPRING TO CLUTCH DISC 5X6 MM
51
RIVET LEAF SPRING TO CLUTCH DISC
52
CLUTCH LINING ASBESTOS-FREE
52
CLUTCH LINING , Replaced By: A0012522910
52
CLUTCH LINING , Replaced By: A0012522910
52
CLUTCH LINING
54
RIVET , Replaced By: A0002521275
54
RIVET LINING WITH INTERMEDIATE SPRING
54
RIVET LINING WITH INTERMEDIATE SPRING,5 563495
56
RIVET LEAF SPRING TO CLUTCH DISC
56
RIVET LINING WITH CLUTCH DISC,5 563495
999
SEAL RING CLUTCH ACTUATION
999
SEAL RING LEVER TO RELEASE SHAFT,5 285575
999
PIN CLUTCH ACTUATION
999
LEVER CLUTCH ACTUATION,4 601610
999
VALVE CLUTCH SLAVE CYLINDER
999
BUSHING ,4 401411, Replaced By: A3852510450, +001A0119978846
999
LEVER (PARTS KIT),CLUTCH ACTUATION
999
GREASE NIPPLE (PARTS KIT) RELEASE BEARING LUBRICATION
999
LOCK RINGTO 000 553 37 01,000 553 39 01,
999
SCREW , Replaced By: N308676018010
999
SNAP RING LEVER TO RELEASE SHAFT,4 601609
999
LOCK WASHER BELL HOUSING TO TRANSMISSION
999
PLUG BELL HOUSING
999
PLUG BELL HOUSING
999
PRESSURE PLATE
999
CLAMP RELEASE FLANGE TO RELEASE LEVER
999
PIN CLUTCH SLAVE CYLINDER
999
VALVE , Replaced By: A3075530107
999
ROD END CLUTCH ACTUATION
999
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0019972141
