Поз.
Артикул
Описание
8
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
8
LINE , Replaced By: A0004296201
16
HOSE ,4 195522
16
HOSE , Replaced By: N071435006002
16
HOSE , Replaced By: A3205730136
24
PLASTIC PIPE RISING PIPE 4X6 MM
24
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
32
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
36
INSULATING HOSE8X0,01 MM
36
INSULATING HOSE RED, ORDER BY THE METER
40
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
40
BANJO UNION , Replaced By: N915052004006
48
SLEEVE LEAK LINE
48
BUSHING , Replaced By: N915062004000
48
BUSHING , Replaced By: N915062004000
56
LOOM TIE LINE MOUNTING
56
LOOM TIE LINE MOUNTING 280 MM
64
SEAL RING LINE CONNECTION
72
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
72
DOUBLE FITTING , Replaced By: A0019972872
72
CONNECTION FITTING , Replaced By: A0039979172
72
TS DOUBLE FITTING SOLENOID VALVE
72
FITTING , Replaced By: A0029906071
72
FITTING , Replaced By: A0039979072
76
FITTING FROM PUMP TO CYLINDER
76
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
76
FITTING , Replaced By: A0019909871
80
SEAL RING LINE CONNECTION
88
HOLLOW SCREW HEATING CONNECTION
96
DOUBLE FITTING , Replaced By: A0019972872
96
TS DOUBLE FITTING SOLENOID VALVE
96
FITTING , Replaced By: A0029906071
96
FITTING , Replaced By: A0039979072
104
VALVE P.T.O.
104
VALVE P.T.O.
104
VALVE P.T.O.
104
VALVE , Replaced By: A0002608057
104
VALVE P.T.O.
104
VALVE , Replaced By: A0002607957
112
REPAIR KITTO 001 997 34 36,002 997 58 36,
112
REPAIR KITHERION,94171034/0711/24V,94172034/0711
112
REPAIR KITTO 001 997 34 36,002 997 58 36,
112
REPAIR KIT , Replaced By: A0012608357
112
REPAIR KITHERION,94171034/0711/24V,94172034/0711
112
SEAL RING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A0005862626
112
MAGNET , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A0005862626
112
SPRING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A0005862626
112
SEAL RING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A0005862626
112
SEAL RING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A0005862626
112
VALVE DISC , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A0005862626
120
SEAL RING LINE CONNECTION
128
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
128
SCREW PLUG , Replaced By: N000908012009
136
HOLLOW SCREW HEATING CONNECTION
140
TS DOUBLE FITTING SOLENOID VALVE
140
FITTING , Replaced By: A0029906071
140
FITTING , Replaced By: A0039979072
140
DOUBLE FITTING , Replaced By: A0019972872
144
ELBOW FITTING CAB FLOOR
144
FITTING OIL LINE CONNECTION
152
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "40"
160
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
160
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
168
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
176
BRACKET BRACKET TO REAR AXLE II,4 195521
184
CLAMP LINE MOUNTING
192
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
192
SCREW CONNECTOR
194
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
196
NUT BALL PIVOT TO LEVER
202
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
202
SCREW , Replaced By: N304017008027
204
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
204
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
204
NUT , Replaced By: N913004008001
206
BRACKET
208
WASHER BRACKET TO FRAME
208
WASHER , Replaced By: N000125017016
210
INSULATING HOSE8X0,01 MM
210
INSULATING HOSE RED, ORDER BY THE METER
213
SCREW STEERING BOX ASSEMBLY TO STEERING SUPPORT
213
SCREW , Replaced By: N308676016006
213
SCREW , Replaced By: N914142016202
214
FITTING FROM 3/2-WAY VALVE TO PRESSURE CONTROL VALVE
214
FITTING , Replaced By: A0009977172
214
BULKHEAD FITTING , Replaced By: A0019973872
215
T-FITTING EXHAUST-BRAKE POWER CYLINDER
216
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
999
NUT
999
EXPANSION PLUG FROM CAB PLUG CONNECTION TO SIDE LAMPS AND TO GROUND
999
GUMMED LABEL , SIMPLE PART-PLEASE HAVE SHOP MADE
999
BRACKET
999
BRACKET ,197582
999
BRACKET , ON 10/20 FROM IDENT NO.:984571, ON 50/60 FROM IDENT NO.:988351
