Поз.
Артикул
Описание
110
BRAKE VALVE
110
BRAKE VALVE , Replaced By: A0014316205
112
REPAIR KIT , Replaced By: A0014306160
112
REPAIR KIT TRAILER CONTROL VALVE TO 001 431 52 05, WABCO
114
ELBOW FITTING AIR RESERVOIR,CONNECTIONS: "31,32"
114
FITTING , Replaced By: A0009907771
116
O-RING CHECK VALVE TO AIR RESERVOIR
118
THRUST RING CHECK VALVE TO AIR RESERVOIR
118
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
120
NUT CHECK VALVE TO AIR RESERVOIR
122
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
124
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
126
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
128
VALVE TWO-WAY VOSS
128
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0024299544
128
VALVE TWO-WAY
128
VALVE TWO-WAY
130
VALVE BODYTO 002 429 95 44
130
VALVE , Replaced By: A0004291182
132
BALLTO 003 429 22 44
134
GASKETTO 003 429 22 44
136
FITTING SHUTTLE VALVE,CONNECTION: "20"
136
FITTING , Replaced By: A0019972372
136
FITTING SHUTTLE VALVE,CONNECTION: "20",5 727399
138
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
140
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
142
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
142
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11","12"
144
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
146
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
146
FITTING , Replaced By: A0009970171
148
T-FITTING CONNECTION: 12, 10/20 FROM CHASSIS 4 270414,50/60 FROM CHASSIS 4 270290
150
O-RING CHECK VALVE TO AIR RESERVOIR
152
THRUST RING CHECK VALVE TO AIR RESERVOIR
152
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
154
NUT CHECK VALVE TO AIR RESERVOIR
158
O-RING CHECK VALVE TO AIR RESERVOIR
160
THRUST RING CHECK VALVE TO AIR RESERVOIR
160
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
162
NUT CHECK VALVE TO AIR RESERVOIR
164
BRACKET
164
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3874300610
166
NUT , Replaced By: N910113010000
166
NUT STRAP TO BRACKET
168
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
168
SCREW SUPPORT TO FENDER
168
SCREW PIPE CLAMP
168
SCREW , Replaced By: N304017008021
168
SCREW , Replaced By: N304017008027
168
SCREW , Replaced By: N304017008018
170
NUT , Replaced By: N913004008001
170
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
172
VALVE PRESSURE LIMIT
174
VALVE REPAIR KIT
174
REPAIR KIT , Replaced By: A0004205455
174
REPAIR KIT , Replaced By: A0024292844
176
FITTING , Replaced By: A0029971372
176
FITTING , Replaced By: A0029971172
176
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
176
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
176
FITTING SHUTTLE VALVE
180
NUT BRACKET TO SIDE MEMBER
182
O-RING CHECK VALVE TO AIR RESERVOIR
184
FITTING AIR RESERVOIR,CONNECTION: "11"
188
O-RING CHECK VALVE TO AIR RESERVOIR
190
THRUST RING CHECK VALVE TO AIR RESERVOIR
190
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
192
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
194
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
198
THRUST RING CHECK VALVE TO AIR RESERVOIR
198
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
200
BRACKET , Replaced By: A3934310840
200
BRACKET PRESSURE RELIEF VALVE
200
BRACKET PRESSURE RELIEF VALVE
200
BRACKET PRESSURE RELIEF VALVE
202
BRACKET PRESSURE RELIEF VALVE
204
SCREW SUPPORT TO FENDER
204
SCREW PIPE CLAMP
204
SCREW , Replaced By: N304017008021
204
SCREW , Replaced By: N304017008018
206
NUT , Replaced By: N913004008001
206
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
208
FITTING , Replaced By: A0029971172
208
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
208
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
210
O-RING CHECK VALVE TO AIR RESERVOIR
212
THRUST RING CHECK VALVE TO AIR RESERVOIR
212
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
214
ELBOW FITTING AIR RESERVOIR,CONNECTIONS: "31,32"
214
FITTING , Replaced By: A0009907771
216
O-RING CHECK VALVE TO AIR RESERVOIR
218
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
218
THRUST RING CHECK VALVE TO AIR RESERVOIR
222
NUT CHECK VALVE TO AIR RESERVOIR
224
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
226
FITTING SHUTTLE VALVE
226
FITTING , Replaced By: A0029971372
228
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
230
NUT BRACKET TO SIDE MEMBER
232
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SEAL RING LINE CONNECTION
999
PLUG TWO-CIRCUIT BRAKE VALVE,CONNECTIONS: "21,22", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KITWABCO
999
REPAIR KITTO A 000 429 11 31
999
FITTING AIR CLEANER
999
PLUG FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
SPRINGTO 000 429 16 30
999
VALVE DISCTO 000 429 48 30
999
VALVE TAPPETTO 000 429 16 30
999
VALVE PARTTO 000 429 16 30
999
NUTTO 000 429 16 30
999
SPRING CAPSULETO 000 429 16 30
999
COVERTO 000 429 16 30,BOSCH
999
SPRING RETAINERVOSS
999
PISTONVOSS
999
SPACER RING ,4 428462
999
REPAIR KITKNORR
999
REPAIR KIT PRESSURE REGULATOR BOSCH,241
999
BRAKE LINE COUPLING , Replaced By: A0004297530
999
COVERWABCO
999
COVERTO 000 429 48 30
999
VALVE CONEBOSCH
999
VALVE CONE , Replaced By: A0004290391
999
REPAIR KIT BRAKE LINE COUPLING TO 000 429 68 30
