Поз.
Артикул
Описание
13
HOUSING BELL HOUSING WITH BUSHINGS,5 285576
13
HOUSING BELL HOUSING WITH BUSHINGS
13
HOUSING BELL HOUSING WITH BUSHINGS
13
HOUSING ,5 285575, Replaced By: A6232500105, +001A6202500155
13
HOUSING ,4 7439865 285575, Replaced By: A6202501205, +001A6202500155
13
HOUSING ,5 285575, Replaced By: A6202501105, +001A6202500155
26
BUSHING RELEASE SHAFT,BOTTOM
39
BUSHING RELEASE SHAFT,BOTTOM 24X27 MM
52
BUSHING RELEASE SHAFT,TOP 35X39 MM
65
BUSHING RELEASE SHAFT,TOP
65
BUSHING ,5 285575, Replaced By: A6202510050, +001A6202500155, +001A0099971547
78
SEAL RING RELEASE SHAFT,TOP
91
SEAL RING RELEASE SHAFT,TOP 40X52X7 MM
91
SEAL RING RELEASE SHAFT,BOTTOM 40X52X11 MM
104
COVER PLATE RELEASE SHAFT,TOP
117
SHAFT (PARTS KIT),RELEASE SHAFT
117
SHAFT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 285575, Replaced By: A3852500014
130
WASHER AS REQUIRED 0.90 MM
130
WASHER AS REQUIRED 1.00 MM
130
WASHER AS REQUIRED 1.20 MM
130
WASHER AS REQUIRED 1.3 MM
130
WASHER AS REQUIRED 1.10 MM
130
WASHER AS REQUIRED 0.80 MM
143
SEAL RING BOTTOM
156
SPACER WASHER RELEASE SHAFT,BOTTOM
169
LOCK RING RELEASE SHAFT,BOTTOM
182
RELEASE LEVER CLUTCH ACTUATION
195
SCREW RELEASE LEVER TO SHAFT
195
SCREW , Replaced By: N000933012102
195
SCREW , Replaced By: N304017012018
208
PLUG BELL HOUSING
208
PLUG BELL HOUSING
221
PLUG BELL HOUSING
234
PLUG BELL HOUSING
247
RELEASE BEARING CLUTCH ACTUATION
247
RELEASE BEARING CLUTCH ACTUATION
260
SPRING RELEASE BEARING TO RELEASE LEVER
273
HOSE RELEASE COLLAR LUBRICATION 220 MM
286
LEVER (PARTS KIT),CLUTCH ACTUATION
286
LEVER (PARTS KIT),CLUTCH ACTUATION
299
ROD END CLUTCH ACTUATION
312
PIN CLUTCH ACTUATION
325
SEAL RING CLUTCH ACTUATION
325
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0019972141
338
LOCK RINGTO 000 553 37 01,000 553 39 01,
351
COVER RELEASE SHAFT,TOP
351
WASHER , Replaced By: A6202540176
351
WASHER LEVER TO RELEASE SHAFT,5 285575
364
SEAL RING LEVER TO RELEASE SHAFT,5 285575
377
SCREW MOUNTING AND RAIL TO LEAF SPRING
377
SCREW PIPE ELBOW TO BRACKET M 10X50
377
SCREW , Replaced By: N304017010030
377
SCREW , Replaced By: N304017010053
380
ANGLE LINE MOUNTING
383
SCREW CONSOLE TO FRAME SIDE MEMBER
383
SCREW , Replaced By: A0079903901
386
LOCK WASHER FITTING TO BRACKET
389
LOOM TIE LINE MOUNTING 280 MM
390
SLAVE CYLINDER , Replaced By: A0012955307
390
SLAVE CYLINDER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 368621, Replaced By: A0012958907
390
SLAVE CYLINDER CLUTCH ACTUATION
390
SLAVE CYLINDER , Replaced By: A0022951007
390
SLAVE CYLINDER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 669429, Replaced By: A0022950407
390
SLAVE CYLINDER CLUTCH ACTUATION
390
SLAVE CYLINDER CLUTCH
403
VALVE CLUTCH SLAVE CYLINDER
403
BLEEDER VALVE , Replaced By: A0004310265
403
VALVE , Replaced By: A3075530107
416
PROTECTIVE CAP , Replaced By: A0004217187
416
PROTECTIVE CAP ,5 962906
429
REPAIR KIT CLUTCH SLAVE CYLINDER
429
REPAIR KIT , Replaced By: A0002900911
442
BRACKET , Replaced By: A3072950840
442
BRACKET CLUTCH ACTUATION
446
BRACKET CLUTCH BOOSTER, 396.3 10/20 6 900235 396.3 50/60 5 353181 396.4 10/20 6 900001 396.4 50/60 5 000001
455
SCREW BRACKET TO SIDE MEMBER
455
SCREW , Replaced By: N304017010002
468
POINTER CLUTCH LINING WEAR, 396.3 10/20 6 900235 396.3 50/60 5 353180 396.4 NOT USED
481
SCREW , Replaced By: N304017006016
481
SCREW PUMP TO BRACKET
494
WASHER , Replaced By: N009021006208
494
WASHER COMPRESSED AIR LINE TO BRACKET
507
LOCK POINTER TO CLUTCH ACTUATION BRACKET, 396.3 10/20 6 900235 396.3 50/60 5 353180 396.4 NOT USED
533
SCREW RADIATOR M 10X45
546
SCREW SUPPORTING ARM TO CYLINDER CRANKCASE M 18X60
546
SCREW , Replaced By: N308676018010
559
LOCK WASHER BELL HOUSING TO TRANSMISSION
562
SLAVE CYLINDER CLUTCH ACTUATION WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
565
SCREW CLUTCH BOOSTER TO BELL HOUSING M 10X30,5 962907
565
SCREW , Replaced By: N914146010114
999
RELEASE BEARING
999
BEARING TOP
999
LOCK
999
BOOT , Replaced By: A0005863129
999
SLAVE CYLINDER CLUTCH ACTUATION
999
CAP CLUTCH LINING WEAR INDICATOR
999
SENDER UNIT LIMITATION OF ENGINE SPEED
999
SEAL RING RELEASE LEVER
999
NEEDLE BEARING RELEASE LEVER
999
LEVER CLUTCH ACTUATION,4 601610
999
FLANGE CLUTCH BOOSTER
999
SCREW CLUTCH LINING WEAR INDICATOR
999
PIN CLUTCH LINING WEAR INDICATOR
999
PIN RELEASE LEVER,5 599536
