Поз.
Артикул
Описание
5
BRAKE LEVER , NO.8650I.......I.......I I II
8
HANDLE , NO.8650I.......I.......I I II .......INO.9985I.......I I II
11
COVERING , NO.8650I.......I.......I I II .......INO.9985I.......I I II
14
COVERING , NO.8650I.......I.......I I II .......INO.9985I.......I I II
17
CONSOLE
17
CONSOLE
20
SCREW CONSOLE TO CAB M 10X80
23
SCREW BRACKET TO SIDE MEMBER
23
SCREW , Replaced By: N304017010002
26
WASHER CONSOLE TO CAB
29
STOP BUFFER. DAMPING RING
32
SCREW CROSS MEMBER TO SIDE MEMBERS
32
SCREW CONNECTOR TO REAR SHIFTING ROD
35
WASHER GROUND CABLE
35
WASHER RADIATOR TO RUBBER MOUNTING
38
NUT BRAKE LEVER TO CONSOLE
41
COVERING AT CONSOLE, NO.8650I.......I.......I I II .......INO.9985I.......I I II
44
BRAKE CABLE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.B 969878, Replaced By: A6884207885
47
BRAKE CABLE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.B 969878, Replaced By: A6884207985
50
LOOM TIE , Replaced By: A3459977390
53
GROMMET
56
SPRING BRAKE CABLE
59
PIN BRAKE CABLE TO BRAKE LEVER
62
NUT BRAKE CABLE TO BRAKE LEVER
65
BRACKET , Replaced By: A3184280240
68
BRACKET BRACKET TO FENDER BRACKET
68
BRACKET TO ENGINE
71
SCREW PLUG SOCKET TO FRAME
74
SCREW , Replaced By: N304017010043
77
NUT , Replaced By: N910113008007
80
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
83
GUIDE PLATE REAR BRAKE CABLE TO BRACKET
86
SCREW PARKING BRAKE VALVE TO INSTRUMENT PANEL,TB108828
89
LOCK WASHER RAIL TO BATTERY SUPPORT
92
CLAMP DELIVERY AND SUCTION LINES TO FRAME 12/15
92
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
94
SCREW BRAKE CABLE TO BRACKET
96
SCREW , Replaced By: N304017006016
98
WASHER PLUG SOCKET TO BRACKET
98
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
101
LOCK WASHER CABLE TO FUSE BOX
104
NUT
104
NUT SPRING-LOADED PUSH ROD
107
CLAMP BATTERY CABLE TO BRACKET
107
CLAMP BRAKE HOSE BRACKET
110
BRACKET
113
GROMMET LINE THRU LEFT SIDE MEMBER
