Поз.
Артикул
Описание
5
PLATE RELAY AND FUSE BOX
8
SCREW CONTROL UNIT
11
NUT HOOK TO BRACKET
11
NUT TWO-WAY VALVE TO BRACKET
14
BRACKET APPARATUS PLATE
17
TREENAIL BRACKET TO WINDOW LEVEL
20
COMBINATION BOLT BRACKET TO WINDOW LEVEL
23
PLATE BRACKET TO WINDOW LEVEL
26
SCREW CONTROL UNIT
29
NUT. CAPTIVE NUT PLATE TO BRACKET
32
FUSE BOX ,070378
32
FUSE BOX , Replaced By: A0005457701
38
FUSE50 A
38
FUSE25A
38
FUSE
41
SCREW TO PLUG THE FREE CONNECTIONS
44
SCREW
47
SPRING WASHER LICENSE PLATE TO BRACKET
50
WASHER FUSE
53
DISC SPRING
56
SCREW STEP SWITCH
56
SCREW HOOK TO BRACKET
59
WASHER FUSE
62
FUSE BOX ,NB953480
62
FUSE BOX ADDITIONAL FLOODLIGHT,MB910567
65
FUSE BOX 12-POLE, TERMINALS 1-2,3-4,5-11 SHUNTED,B 951658
65
FUSE BOXNO.1
68
GUIDE SIGN FUSE BOX
71
SCREW FUSE BOX TO APPARATUS PLATE
74
NUT , Replaced By: N913004006001
77
FUSEA16
77
FUSE , Replaced By: N072581008101
77
FUSE , Replaced By: N072581005100
83
SENDER UNIT HAZARD WARNING LIGHT
86
SWITCH,AUTOMATIC WIPER INTERMITTENT ACTION
89
SCREW BRACKET MOUNTING
92
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
92
WASHER CAN NEUTRAL POINT ON EQUIPMENT PLATE
95
NUT
98
CASE DIODE CASE,D 055050
101
SCREW , Replaced By: N000000001146
104
NUT , Replaced By: N913004006001
107
WASHER PLUG SOCKET TO BRACKET
107
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
110
RESISTOR
113
SCREW MOUNTING PARTS M 5X12, Replaced By: N000000002035
116
LOCK WASHER BRACKET TO STEERING COLUMN END
119
RELAY , Replaced By: A0035459605
119
RELAY , Replaced By: A3865427819
119
RELAY AT APPARATUS PLATE 50 A
119
RELAYA33, Replaced By: A0009822123
119
RELAY , Replaced By: A3865428319
