Поз.
Артикул
Описание
5
VALVE 3/2-WAY KNORR
5
VALVE 3/2-WAY WABCO
5
VALVE 3/2-WAY VOSS
5
VALVE 3/2-WAY BOSCH
8
SEAL RING TOP WABCO
11
SEAL RING INSIDE WABCO
14
SPRING INSIDE WABCO
17
SYMBOL PLATE P.T.O. I
20
WASHER AT TWO-WAY VALVE
23
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
26
HOLLOW SCREW LINE CONNECTION
29
SEAL RING LINE CONNECTION
32
PLASTIC PIPE RISING PIPE 4X6 MM
32
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
35
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
38
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
38
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
41
SEAL RING LINE CONNECTION
44
HOLLOW SCREW HEATING CONNECTION
47
LOOM TIE365 MM
47
LOOM TIE , Replaced By: A3719977090
50
ANGLE LINE MOUNTING
53
SCREW , Replaced By: N910105010040
56
LOCK WASHER ANGLE TO TRANSMISSION
59
PLASTIC PIPE AERATION, ORDER BY THE METER
62
FITTING (PARTS KIT),LINE RUPTURE
65
BANJO UNION HEATING CONNECTION,K 169122
