Поз.
Артикул
Описание
8
MOUNTING FRAME BATTERY MOUNTING
11
CLAMPING SCREW BATTERY MOUNTING
14
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
17
NUT CLAMP TO BRACKET
20
ELECTRIC CABLE , Replaced By: N072551070880, +001N046234010007, +001N072332013100
23
POSITIVE CABLE FROM BATTERY I TO BATTERY II
35
NEG. CABLE , Replaced By: N072551070880, +001N046234010007, +001N072332013100
35
ELECTRIC CABLE , Replaced By: N922002070000
35
ELECTRIC CABLE , Replaced By: A6735460013
35
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
38
CABLE SHOE BATTERY CABLE 10-70 MM
41
SOLDERING TERMINAL BATTERY POS. POLE 70 MM2
44
NEG. CABLE , Replaced By: N072551070880, +002N046234010007
44
ELECTRIC CABLE , Replaced By: N922002070000
44
ELECTRIC CABLE , Replaced By: A6735460013
44
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
47
CABLE SHOE BATTERY MASTER SWITCH
50
NEG. CABLE , Replaced By: N072551070880, +001N046234010007, +001N072332013200
59
GROUND STRAP AT LEFT SIDE MEMBER
62
SCREW END PIECE TO EXHAUST PIPE M 10X25
62
SCREW REAR EXHAUST PIPE TO MUFFLER
62
SCREW , Replaced By: N910105010011
65
WASHER A. WASHER BRACKET TO LEFT SIDE MEMBER
68
NUT , Replaced By: N910113010000
68
NUT EXHAUST PIPE TO SIDE MEMBER
71
SWITCH ELECTRO-MAGNETIC
74
SCREW GROUND STRAP TO ENGINE
74
SCREW GROUND STRAP TO ENGINE
77
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
80
WASHER , Replaced By: N000125015019
83
SCREW BRACKET TO FRAME SIDE MEMBER M 8X75
86
WASHER , Replaced By: N009021008213
89
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
92
NUT , Replaced By: N304032008006
95
PROTECTIVE TUBE , Replaced By: A3055460385
95
PROTECTIVE TUBE FLEXIBLE SHAFT 4000 MM, UP TO CHASSIS 022725 EXCEPT FOR SEE FOOTN.67,ALSO INSTALLED ON 022728,022734,022744,022746,022749,022752
98
CLAMP SUCTION LINE
101
SCREW COVER PLATE TO BRACKET
101
SCREW DELIVERY AND SUCTION LINES TO ENGINE, FRONT M 6X35
104
WASHER , Replaced By: N009021006208
107
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
110
NUT BALL PIVOT TO LEVER
113
SCREW COVER PLATE TO BRACKET
999
SOLDERING TERMINAL BATTERY NEG. POLE 70 MM2
