Поз.
Артикул
Описание
92
BRAKE VALVE (TRAILER CONTROL VALVE) KNORR, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
92
BRAKE VALVEWABCO, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING
92
BRAKE VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0034313405
98
BRAKE VALVEGRAU, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING
104
VALVE SEATTO GRAU
110
SEAL RING22.3X2.4 MM,GRAU
116
SEAL RING64.77X2.62,TO GRAU
122
SEAL RING18X2.5,TO GRAU
128
SEAL RING44.2X3,TO GRAU
134
SEAL RING30X2,TO GRAU
140
SEAL RING7X1.5,TO GRAU
146
SEAL RING90X3,TO GRAU
146
SEAL RING100X3,TO GRAU
158
SEAL RING9X1.5,TO GRAU
164
SEAL RING23.47X2.62,TO GRAU
164
SEAL RINGTO GRAU
176
GASKET KIT SEAL RING TO 001 431 67 05,BOSCH 061 214
182
REPAIR KITTO 001 431 67 05, BOSCH 061 010
182
REPAIR KIT VALVE DISC TO 001 431 67 05,BOSCH 061 214
182
REPAIR KIT , Replaced By: A0004301109
182
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
182
REPAIR KITTO KNORR
182
REPAIR KITTO WABCO
188
REPAIR KITTO GRAU
194
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
200
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
206
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
212
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
218
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
218
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
224
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
230
BRACKET TRAILER CONTROL VALVE,K 213085
236
NUT BRACKET TO BRACKET
242
SCREW BRACKET TO FRAME M 8X35
248
NUT BRACKET TO BRACKET
254
BRAKE LINE COUPLING SUPPLY, RED "BOSCH"
254
BRAKE LINE COUPLING SUPPLY, RED "GRAU"
254
BRAKE LINE COUPLING SUPPLY, RED "KNORR"
254
BRAKE LINE COUPLING SUPPLY, RED "WABCO"
254
BRAKE LINE COUPLING BRAKE,YELLOW "BOSCH"
254
BRAKE LINE COUPLING BRAKE,YELLOW "GRAU"
254
BRAKE LINE COUPLING BRAKE,YELLOW "KNORR"
254
BRAKE LINE COUPLING BRAKE,YELLOW "WABCO"
260
SEAL RING25X2 MM,BOSCH
260
SEAL RING30X2 MM,BOSCH
260
SEAL RING"GRAU"
266
SEAL RING33X2.5 MM,BOSCH
272
SEAL RING22X4 MM,BOSCH
278
VALVE TAPPET22X4 MM,BOSCH
290
REPAIR KIT BRAKE LINE COUPLING "WABCO"
296
BRACKET BRAKE LINE COUPLINGS,KAN 72/97
302
RIVET14X70 MM, TO BE ADAPTED DURING ASSEMBLY
302
RIVET BRACKET TO FRAME
304
SCREW EXHAUST PIPE TO SIDE MEMBER
306
NUT EXHAUST PIPE TO SIDE MEMBER
308
FITTING BRAKE LINE COUPLING TO BRACKET
314
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
320
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
326
NUT BRACKET TO SIDE MEMBER
332
VALVE PARKING BRAKE VALVE KNORR,008097
332
VALVE PARKING BRAKE KNORR, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING
332
VALVE PARKING BRAKE BOSCH, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
332
VALVE PARKING BRAKE WABCO, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING
338
PROTECTIVE CAPKNORR
338
PROTECTIVE CAPTO BOSCH
338
PROTECTIVE CAPTO WABCO
344
HANDLEKNORR
344
HANDLETO BOSCH
344
HANDLETO WABCO
350
REPAIR KITTO 002 430 98 81,99 81,KNORR
350
REPAIR KITTO WABCO
350
REPAIR KIT , Replaced By: A0034303281
350
REPAIR KITTO BOSCH
356
T-FITTING EXHAUST BRAKE 3/2-WAY VALVE
362
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
362
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
368
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
374
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
376
HOLLOW SCREW , Replaced By: N915036010108
378
SEAL RING FUEL LINE TO FEED PUMP
380
SCREW REAR EXHAUST PIPE TO MUFFLER
380
SCREW BRACKET TO SIDE MEMBER
