Поз.
Артикул
Описание
5
METAL SPRING BELLOWS ,4 9579425 498312
20
SCREW STRUT TO CONSOLE
23
LOCK WASHER FITTING TO BRACKET
26
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
32
CONNECTOR PULL ROD TO LEVER
35
CLAMP CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
38
CLAMP , Replaced By: N000000000665
41
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
44
WASHER , Replaced By: N000125008443
47
COTTER PIN PULL ROD
71
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE KNORR,5 234164
71
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE,5 234164
71
BRAKE PRESSURE REGULATORWABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
77
REPAIR KIT BRAKE POWER REGULATOR WABCO
77
REPAIR KIT VALVE BOSCH
77
REPAIR KIT BRAKE POWER REGULATOR TO 002 431 05 12,KNORR
77
REPAIR KIT COVERING TO 001 431 36 12
77
REPAIR KIT BRAKE POWER REGULATOR BOSCH
83
BRACKET BRAKE POWER REGULATOR
86
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
86
NUT , Replaced By: N913004008001
89
SCREW BRACKET TO SIDE MEMBER
89
SCREW , Replaced By: N304017010002
101
LEVER BRAKE POWER REGULATOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
104
GUIDE SIGN LOAD-DEPENDING BRAKE
107
ADHESIVE FOIL GUIDE SIGN
124
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
127
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
130
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
133
VALVE (RELAY VALVE) GRAU
133
VALVE (RELAY VALVE) KNORR
133
VALVE (RELAY VALVE) WABCO
133
VALVE (RELAY VALVE) BOSCH
136
SEAL RING22.3X2.4 MM,GRAU
139
VALVE SEATGRAU
142
SEAL RINGTO 000 429 28 95,GRAU
145
SEAL RING28X2 MM,GRAU
148
SEAL RING86X2 MM,GRAU
151
GASKET34X2X6 MM,GRAU
152
VALVEBOSCH
154
REPAIR KITKNORR
154
REPAIR KITWABCO
154
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
166
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
166
NUT , Replaced By: N913004008001
169
BRACKET RELAY VALVE,5 484806
172
BRACKET RELAY VALVE, NOT USED
175
SCREW REAR EXHAUST PIPE TO MUFFLER
178
NUT , Replaced By: N910113010000
181
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
184
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
187
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
188
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
190
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
