Поз.
Артикул
Описание
5
ACCELERATOR PEDAL (PARTS KIT), RANGE OF DELIVERY INCLUDES: 1X 655 301 00 93, 3X 000965 006077
8
PAD ACCELERATOR PEDAL
11
SCREW ACCELERATOR PEDAL
14
SHIM ACCELERATOR PEDAL
17
SCREW PEDAL TO CAB FLOOR
20
BOOT ACCELERATOR PEDAL
21
GUIDE RAIL ACCELERATOR PEDAL TO FLOOR PLATE
23
SCREW ACCELERATOR PEDAL TO CAB M 6X25
26
STOP ACCELERATOR PEDAL
29
SCREW VALVE TO BRACKET, Replaced By: N304014008002
32
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
35
BALL PIVOT LOAD SENSOR
38
NUT AT FILTER BRACKET
41
ROD LOAD SENSOR CONTROL
44
BALL SOCKET PULL ROD TO LEVER
47
NUT BALL SOCKET TO ROD
50
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
54
BEARING BRACKET INTERMEDIATE LEVER,5 943507
56
SCREW , Replaced By: N910142008001
56
SCREW , Replaced By: N910143008002
63
LEVER (INTERMEDIATE LEVER)
65
BALL STUD. BALL PIVOT TOP B10X4,5 MM
69
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
71
COVERING INTERMEDIATE BEARING
74
LOCK PLATE INTERMEDIATE BEARING
75
ROD FROM INTERMEDIATE LEVER TO ENGINE
77
PULL ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER
83
BALL SOCKET ROD TO BALL PIVOT
86
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
87
YOKE SHIFTING ROD TO INTERMEDIATE LEVER
89
SECURING CLIP. CIRCLIP
92
PIN ROD TO LEVER
95
WASHER PULL ROD TO SHIFT LEVER
98
COTTER PIN ROD TO INTERMEDIATE LEVER
101
SPRING WASHER , Replaced By: N000137008212
101
SPRING WASHER BRAKE SHOE WITH LINING
