Поз.
Артикул
Описание
5
CONNECTOR LEFT
8
CONNECTOR RIGHT
11
SCREW EXHAUST PIPE TO EXHAUST MANIFOLD
14
NUT EXHAUST PIPE TO EXHAUST MANIFOLD
17
FLEXIBLE METAL TUBE CONNECTOR
20
COLLAR EXHAUST LINE FLEXIBLE METAL TUBE
23
CLAMP FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
26
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
26
SCREW , Replaced By: N304017008027
29
NUT BRACKET TO BRACKET
32
EXHAUST PIPE FRONT,REAR LEFT PART,5 535799
38
EXHAUST PIPE FRONT,REAR RIGHT PART,5 535799
47
BRACKET RIGHT EXHAUST PIPE
47
BRACKET LEFT EXHAUST PIPE
53
CLAMP FLEXIBLE METAL TUBE TO EXHAUST PIPE
56
SCREW , Replaced By: N910105010011
59
NUT EXHAUST PIPE TO SIDE MEMBER
62
SCREW REAR EXHAUST PIPE TO MUFFLER
65
NUT EXHAUST PIPE TO SIDE MEMBER
80
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
83
SCREW SUPPORT TO FENDER
83
SCREW , Replaced By: N304017008018
86
NUT BRACKET TO BRACKET
89
EXHAUST MUFFLER
999
WASHER , Replaced By: N000125008443
