Поз.
Артикул
Описание
5
VALVE 3/2-WAY VOSS
5
VALVE 3/2-WAY WABCO
5
VALVE 3/2-WAY BOSCH
5
VALVE 3/2-WAY KNORR
12
SPRING INSIDE WABCO
19
SEAL RING INSIDE WABCO
19
SEAL RING
26
SEAL RINGWABCO
26
SEAL RING
33
SYMBOL PLATE P.T.O. I
40
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
47
WASHER AT TWO-WAY VALVE
54
HOLLOW SCREW LINE CONNECTION
61
SEAL RING LINE CONNECTION
68
PLASTIC PIPE RISING PIPE 4X6 MM
75
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
75
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
82
HOLLOW SCREW HEATING CONNECTION
89
SEAL RING LINE CONNECTION
96
LOOM TIE
103
ANGLE LINE MOUNTING
110
SCREW , Replaced By: N910105010040
117
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
PROPELLER SHAFT , Replaced By: A6544106802, +002A9424100131
999
PROPELLER SHAFT , Replaced By: A6544103504, +001A9424100131
999
BRACKET PROPELLER SHAFT BEARING I,RIGHT
999
BRACKET PROPELLER SHAFT BEARING I,LEFT
999
REINFORCEMENT BRACKET TO BRACKET
999
WASHER
999
WASHER
999
NUT
999
SCREW
999
NUT
999
BRACKET FRONT EXHAUST PIPE TO BRACKET
999
BRACKET REAR EXHAUST MUFFLER
999
METAL SPRING BELLOWS ELECTROMAGNET VALVE
999
METAL SPRING BELLOWS
999
LINE FROM SHUTTLE VALVE TO LEFT SIDE MEMBER, ORDER BY THE METER
999
LINE FROM TWO-CIRCUIT BRAKE VALVE TO SHUTTLE VALVE, ORDER BY THE METER
999
BRACKET
999
BRACKET
999
VALVE AIR SPRING VALVE
999
SHIM LEFT
999
BUSHING
999
PLATE
999
SHIM RIGHT
999
PIN
999
PLATE
999
LEVER
999
MOUNTING BOW
999
SPRING CLAMPTO 371 320 72 05, 79 05
999
SCREWTO 371 320 72 05, 79 05
999
SCREW
999
REAR SPRING 12-LEAF, REAR SPRING II
999
REAR SPRING 15-LEAF, REAR AXLE I
999
REAR SUBFRAME RIGHT
999
REAR SUBFRAME LEFT
