Поз.
Артикул
Описание
5
RUBBER BUFFER SPRING STOP
8
PLATE , Replaced By: A6203310026
11
SCREW BRACKET TO SIDE MEMBER,5 597425
11
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
16
CONNECTOR LEFT FRONT
16
CONNECTOR LEFT BOTTOM, AND RIGHT TOP
16
CONNECTOR LEFT
24
CONNECTOR RIGHT
24
CONNECTOR RIGHT FRONT
24
CONNECTOR RIGHT FRONT
28
SCREW , Replaced By: N000931012186
28
SCREW CONNECTOR TO EXHAUST MANIFOLD
32
NUT CONNECTOR TO EXHAUST MANIFOLD
36
FLEXIBLE METAL TUBE CONNECTOR
36
FLEXIBLE METAL TUBE FRONT EXHAUST PIPE FRONT PART TO REAR PART
40
COLLAR EXHAUST LINE FLEXIBLE METAL TUBE
40
COLLAR FRONT EXHAUST PIPE FRONT PART TO REAR PART
44
CLAMP FLEXIBLE METAL TUBE TO EXHAUST PIPE
44
CLAMP FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
48
SCREW SUPPORT TO FENDER
48
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
48
SCREW , Replaced By: N304017008018
48
SCREW , Replaced By: N304017008027
52
NUT , Replaced By: N913004008001
52
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
60
EXHAUST PIPE FRONT,REAR LEFT PART,5 130488
60
EXHAUST PIPE FRONT,REAR LEFT PART
60
EXHAUST PIPE FRONT,REAR LEFT PART,5 153110
72
EXHAUST PIPE FRONT,REAR RIGHT PART,5 130488
72
EXHAUST PIPE FRONT,REAR RIGHT PART
72
EXHAUST PIPE FRONT,REAR RIGHT PART,5 130488
96
BRACKET LEFT EXHAUST PIPE
96
BRACKET RIGHT EXHAUST PIPE
104
SCREW REAR EXHAUST PIPE TO MUFFLER
104
SCREW BRACKET TO SIDE MEMBER
104
SCREW , Replaced By: N304017010002
108
NUT , Replaced By: N910113010000
112
CLAMP AT CROSS MEMBER
112
CLAMP FLEXIBLE METAL TUBE TO EXHAUST PIPE
116
SCREW , Replaced By: N304017010002
116
SCREW BRACKET TO SIDE MEMBER
120
NUT , Replaced By: N910113010000
132
FITTING REAR EXHAUST PIPE TO MUFFLER
132
FITTING INTERMEDIATE PIECE,FRONT,5 193595
132
FITTING INTERMEDIATE PIECE,FRONT
136
SCREW , Replaced By: N304017010002
136
SCREW BRACKET TO SIDE MEMBER
140
SCREW , Replaced By: N304017008027
140
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
144
NUT , Replaced By: N910113010000
148
NUT , Replaced By: N913004008001
148
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
160
CLAMP , Replaced By: N071555090502
164
CLAMP PROTECTIVE PLATE TO EXHAUST PIPE
164
CLAMP , Replaced By: N071555094502
168
CLAMP INTERMEDIATE PIECE
168
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
168
CLAMP EXHAUST PIPE TO CONNECTION FITTING
168
CLAMP EXHAUST PIPE TO CONNECTION FITTING
180
EXHAUST PIPE FROM CONNECTION FITTING TO EXHAUST MUFFLER,5 130488
184
EXHAUST PIPE FROM CONNECTION FITTING TO EXHAUST MUFFLER,5 224330
184
EXHAUST PIPE FROM CONNECTION FITTING TO EXHAUST MUFFLER,5 193594
188
BRACKET SHOCK ABSORBER,5 523852
200
SCREW REAR EXHAUST PIPE TO MUFFLER
200
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
204
NUT , Replaced By: N910113010000
208
CLAMP EXHAUST PIPE
208
CLAMP , Replaced By: N071555090502
208
CLAMP , Replaced By: A6554920340
212
SCREW , Replaced By: N304017008027
212
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
212
SCREW REAR EXHAUST PIPE TO MUFFLER
216
NUT , Replaced By: N910113010000
216
NUT , Replaced By: N913004008001
216
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
220
PROTECTIVE PLATE , Replaced By: A6484920030
220
PROTECTIVE PLATE EXHAUST PIPE
228
SCREW , Replaced By: N304017008008
232
SPRING WASHER , Replaced By: N000137008212
