Поз.
Артикул
Описание
12
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
24
PRESSURE PLATE CLUTCH PRESSURE PLATE
36
FLANGE CLUTCH PRESSURE PLATE
48
SPINDLE RELEASE LEVER,CLUTCH PRESSURE PLATE
60
SLEEVE CLUTCH PRESSURE PLATE
72
SCREW RELEASE LEVER,BRACKET
84
NUT FOR BRACKETS
96
LOCK FOR BRACKETS
108
SPRING SUSPENDED BELOW LEAF SPRING
108
SPRING SUSPENDED BELOW LEAF SPRING
120
PRESSURE SPRING SPRING STEEL WIRE DIA., 4.00 MM
120
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.5 MM
120
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.75 MM
132
LEAF SPRING THIGH SPRING SUSPENDED BELOW LEAF SPRING
147
RELEASE LEVER CLUTCH ACTUATION
150
SPINDLE FOR BRACKETS
153
BRACKET FOR BEDDING THE LEVERS IN CLUTCH PRESSURE PLATE
156
ROLLER FOR BEDDING THE LEVERS IN BRACKETS
168
LOCK PLATE RELEASE LEVER TO SHAFT
180
CLUTCH DISC ASBESTOS-FREE LINING
180
CLUTCH DISC , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0092504503
180
CLUTCH DISC , Replaced By: A0062508703
192
RIVET LEAF SPRING TO CLUTCH DISC
192
RIVET LEAF SPRING TO CLUTCH DISC 5X6 MM
204
RIVET LINING WITH CLUTCH DISC
204
RIVET , Replaced By: A0002524875
204
RIVET , Replaced By: A0002524675
204
RIVET , Replaced By: A0002523775
216
LEAF SPRING
216
LEAF SPRING , REBORE HOLE IN SUPPORTING PLATE FROM 5.2MM TO 6.2MM, Replaced By: A0002523919, +002A0002523975
228
CLUTCH LINING , Replaced By: A0022520010
228
CLUTCH LINING , Replaced By: A0012528310
240
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
240
LOCK WASHER FUSE
252
SCREW CONSOLE TO CAB M 10X80
