Поз.
Артикул
Описание
4
BRAKE HOSE FROM AIR COMPRESSOR TO PRESSURE REGULATOR
4
BRAKE HOSE COMPRESSED AIR LINE TO COMPRESSED AIR LINE
8
ELBOW FITTING BUTT SCREW CONNECTION "20",5 271048
10
SEAL RING LINE CONNECTION
12
THRUST RING SUCTION LINE TO OIL PUMP
14
NUT , Replaced By: N080705026003
16
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
16
LINE FROM T-FITTING TO PRESSURE REGULATOR, ONLY APPLICABLE FOR TURKEY
16
LINE FROM CONNECTOR TO T-FITTING, ONLY APPLICABLE FOR TURKEY
16
LINE FROM AIR COMPRESSOR TO COMPRESSED AIR HOSE, ONLY APPLICABLE FOR TURKEY
18
UNION NUT BUTT SCREW CONNECTION
20
GLAND LINE CONNECTION
36
T-FITTING
37
THRUST RING COMPRESSED AIR LINE TO AIR RESERVOIR AND TO T-FITTING
40
CLAMP LINE MOUNTING
42
CLAMP LINE MOUNTING
42
CLAMP BREATHER LINE TO BRACKET
44
CLAMP , Replaced By: A1109950401
46
SCREW CAB FLOOR COVERING M 6X25
49
SCREW , Replaced By: N304017006020
52
NUT , Replaced By: N910113006001
55
WASHER COMPRESSED AIR LINE TO BRACKET
55
WASHER , Replaced By: N009021006208
90
SEAL RING TO 18-MM-DIA. COMPRESSED AIR LINES
205
LINE EXHAUST BRAKE, LENGTH AVAILABLE: 3000 MM
205
LINE FROM TWO-CIRCUIT BRAKE VALVE TO HOSE, ONLY APPLICABLE FOR TURKEY
205
LINE FROM TWO-CIRCUIT BRAKE VALVE TO HOSE, ONLY APPLICABLE FOR TURKEY
208
UNION NUT
212
SEAL CONE
212
GLAND , Replaced By: A0019901667
216
HOSE PRESSURE GAUGE
224
TS DOUBLE FITTING SOLENOID VALVE
224
FITTING , Replaced By: A0029906071
