Поз.
Артикул
Описание
70
VALVE (RELAY VALVE)
70
PRESSURE CONTROL VALVE. RELAY VALVE PARKING BRAKE WABCO, REPAIR IMPOSSIBLE
73
MUFFLERBOSCH, TO 004 429 80 44
80
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
90
NUT HORN TO BRACKET M8
210
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16, VOSS 232
210
SCREW. UNION SCREW LINE CONNECTION
210
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M 22, VOSS 232
210
SCREW. UNION SCREW LINE CONNECTION
210
SCREW. UNION SCREW , Replaced By: A0009973734
253
LOCK LINE CONNECTION
253
LOCK , Replaced By: A0009945448
253
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
256
LOCK RING LINE CONNECTION
256
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
256
SEAL RING , Replaced By: A0009940747
340
RELAY VALVEWABCO
340
RELAY VALVE. VALVE (RELAY VALVE)
350
VALVE FRONT AXLE II RELAY VALVE "WABCO"
350
VALVE FRONT AND REAR AXLE BRAKE PRESSURE KNORR 45.01
360
NUT HORN TO BRACKET M8
370
380
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
390
NUT BRACKET TO SIDE MEMBER M12X1.5
410
SCREW. UNION SCREW LINE CONNECTION
410
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M 22, VOSS 232
410
SCREW. UNION SCREW LINE CONNECTION
410
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16, VOSS 232
410
SCREW. UNION SCREW , Replaced By: A0009973734
425
LOCK , Replaced By: A0009945448
425
LOCK LINE CONNECTION
425
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
430
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
430
LOCK RING LINE CONNECTION
430
SEAL RING , Replaced By: A0009940747
