Поз.
Артикул
Описание
12
ELECTRIC CABLE FROM CHASSIS/CAB CONNECTION POINT TO TELL-TALE LAMP
17
PIN BUSHING HOUSING 5-POLE
22
PIN BUSHING HOUSING BIPOLAR
27
PIN BUSHING HOUSING UNIPOLAR
32
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
37
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
37
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
37
PIN BUSHING , Replaced By: A0075458226
42
LOOM TIE LINE MOUNTING 280 MM
47
ELECTRIC CABLE FROM CHASSIS/CAB TO CURRENT-SUPPLY/ BUZZER-SIGNAL-SYSTEM PLUG-SOCKET,5 000628
47
ELECTRIC CABLE FROM CHASSIS/CAB TO CURRENT-SUPPLY/ BUZZER-SIGNAL-SYSTEM PLUG-SOCKET,5 000629
52
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
57
PLUG SOCKET 6-POLE
62
BOOT
67
LOOM TIE LINE MOUNTING 280 MM
72
TELL-TALE LAMP LESS LENS
77
LENS BUZZER SIGNAL SYSTEM
82
BULB TELL-TALE LAMP
87
BUZZER AUDIBLE WARNING
87
BUZZER COOLING WATER TEMPERATURE WARNING, TO BE ADAPTED DURING ASSEMBLY
92
PLUG SOCKET BUZZER
97
CAP BUZZER
102
BRACKET PLUG SOCKET
107
SCREW PLUG SOCKET TO BRACKET
112
LOCK WASHER T-FITTING TO BRACKET
117
BRACKET CABLE TO BUZZER SIGNAL SYSTEM PLUG SOCKET
122
SCREW END PIECE TO EXHAUST PIPE M 10X25
127
NUT , Replaced By: N910113010000
127
NUT STRAP TO BRACKET
132
LOOM TIE LINE MOUNTING 280 MM
137
RELAYA33
137
RELAY , Replaced By: A0035459605
137
RELAY , Replaced By: A0035459605
137
RELAYA33, Replaced By: A0009822123
147
CONTACTOR RADIOPHONE BATTERY
152
BRACKET RELAY
157
SCREW , Replaced By: N304017008016
157
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
162
NUT , Replaced By: N913004008001
162
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
167
SCREW SOLENOID VALVE TO BRACKET
172
NUT IN CASE OF SUBSEQUENT INSTALLATION
172
NUT , Replaced By: N304032005005
177
LOCK WASHER BRACKET TO STEERING COLUMN END
999
PIN BUSHING HOUSING UNIPOLAR
