Поз.
Артикул
Описание
3
EXHAUST PIPE FRONT
3
EXHAUST PIPE FRONT
13
STRUT BUMPER AT TORSION BAR
23
EXHAUST MUFFLER WITH PIPE FRONT
23
EXHAUST MUFFLER WITH PIPE FRONT
28
REAR EXHAUST PIPE (TAIL PIPE)
28
REAR EXHAUST PIPE (TAIL PIPE), TO BE ADAPTED DURING ASSEMBLY
33
SUPPORT , Replaced By: A3834920616
33
SUPPORT , Replaced By: A3834921016
33
SUPPORT FRONT EXHAUST PIPE
33
SUPPORT FRONT EXHAUST PIPE
53
SUPPORT FRONT EXHAUST PIPE
63
SUPPORT FRONT EXHAUST PIPE
78
SCREW BRACKET TO FRAME SIDE MEMBER
87
NUT END PIECE TO EXHAUST PIPE
150
BRACKET FRONT EXHAUST PIPE TO BRACKET,4 484038
150
BRACKET EXHAUST PIPE, TO BE ADAPTED DURING ASSEMBLY
150
BRACKET ,4 484038
150
BRACKET FRONT EXHAUST PIPE,4 484037
150
BRACKET ,4 484038
150
BRACKET , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A3834927941
159
BRACKET FRONT EXHAUST PIPE TO BRACKET
159
BRACKET FRONT EXHAUST PIPE
180
CLAMP EXHAUST PIPE TO BRACKET
183
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
184
NUT , Replaced By: N910113010000
184
NUT STRAP TO BRACKET
195
RUBBER BUFFER BRACKET TO SUPPORT
204
NUT STRAP TO BRACKET
204
NUT , Replaced By: N910113010000
213
SCREW , Replaced By: N304017008034
222
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
222
NUT , Replaced By: N913004008001
225
PROTECTIVE PLATE RADIATOR
231
PROTECTIVE PLATE BEHIND EXHAUST MUFFLER
231
PROTECTIVE PLATE BEHIND EXHAUST MUFFLER
249
SCREW PIPE CLAMP
249
SCREW , Replaced By: N304017008021
258
NUT , Replaced By: N913004008001
258
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
267
PROTECTIVE PLATE IN FRONT OF EXHAUST MUFFLER
276
SCREW COVER PLATE TO BRACKET
285
SPRING WASHER LICENSE PLATE TO BRACKET
294
BRACKET PROTECTIVE PLATE
303
SCREW BRACKET TO FRAME,4 439997
312
WASHER
321
NUT RETAINER LICENSE PLATE TO BRACKET
321
NUT RETAINER , Replaced By: A0019906791
330
BRACKET LICENSE PLATE
339
SCREW LICENSE PLATE TO BRACKET
339
SCREW , Replaced By: N304017006020
348
SPRING WASHER LICENSE PLATE TO BRACKET
999
RUBBER BUFFER EXHAUST MUFFLER
999
CONNECTOR FRONT,505802
999
BRACKET , Replaced By: A3834927941
999
STRUT LEFT, NOT USED
999
EXHAUST PIPE ,4 439996, Replaced By: A3834900819, +001A3834929141
999
EXHAUST PIPE ,4 439996, Replaced By: A3834900919, +001A3834929141
999
EXHAUST MUFFLER WITH PIPE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.:4 484037, Replaced By: A3834902115
999
EXHAUST MUFFLER WITH PIPE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.:4 484037, Replaced By: A3834902015
999
PROTECTIVE PLATE FUEL TANK
999
EXHAUST MUFFLER WITH PIPE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.:4 484037, Replaced By: A3834901815
999
EXHAUST MUFFLER WITH PIPE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.:4 484037, Replaced By: A3834901715
999
EXHAUST MUFFLER WITH PIPE , FOR THE NEW PART NO.,SEE STANDARD VERSION, Replaced By: A3834900301, +001A3604928504
999
EXHAUST MUFFLER WITH PIPE , FOR THE NEW PART NO.,SEE STANDARD VERSION, Replaced By: A3834900301, +001A3604928504
999
CLAMP , Replaced By: A3834920940
999
REAR EXHAUST PIPE , Replaced By: A3604928504
