Поз.
Артикул
Описание
5
BEARING BODY FAN DRIVE
8
SCREW TORSION BAR TO REAR AXLE M 8X70
9
SCREW VALVE TO BRACKET
9
SCREW , Replaced By: N304014008007
10
NUT BATTERY CASE
11
WASHER TRAILER PLUG SOCKET TO BRACKET
14
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
17
FAN SHAFT
18
FAN SHAFT ,D 276362
18
FAN SHAFT ,D 180260
20
CYLINDR. ROLLER BEARING FAN DRIVE
21
SPACER TUBE
23
LOCK RING52X2 MM
26
BALL BEARING. GROOVED BALL BEARING FAN DRIVE,D 276362
26
BALL BEARING FAN DRIVE
29
RADIAL SEAL RING
29
SEAL RING CASE COVER
29
SEAL RING
29
RADIAL SEAL RING , Replaced By: A0019978447
32
PULLEY FAN DRIVE
36
HUB FAN,D 180260
36
HUB ,D 276362 NOT USED
41
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
41
NUT TRAILER COUPLING TO REAR CROSS MEMBER
41
NUT SPRING SEAT AND BEARING BRACKET TO REAR AXLE
44
SCREW PLUG AIR DEHYDRATOR
44
SCREW PLUG 4/2-WAY VALVE
45
GREASE NIPPLE PROTECTIVE TUBE
47
SEAL RING PNEUMATIC VALVE
50
FAN POWER SAVER FAN
50
FAN ,D 173028
50
FAN POWER SAVER FAN,D 180260
53
SCREW LINES TO BRACKET
53
SCREW , Replaced By: N304017010040
56
LOCK
173
WASHER GROUND CABLE
176
LOCK WASHER , Replaced By: N912004010102
179
NUT BRACKET TO SIDE MEMBER
179
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
188
V-BELT FROM TIGHTENER PULLEY TO FAN DRIVE 1725 MM,D 180261D 434768
188
V-BELT FAN
188
V-BELT FROM TIGHTENER PULLEY TO FAN DRIVE 1735 MM,D 434769
188
V-BELT FROM TIGHTENER PULLEY TO FAN DRIVE,D 163707D 173027
188
V-BELT FROM VIBRATION DAMPER TO TIGHTENER PULLEY,D 173028
188
V-BELT FAN DRIVE
188
V-BELT TIGHTENER PULLEY
188
V-BELT FROM TIGHTENER PULLEY TO FAN DRIVE 12X1250 MM,D 180260
188
V-BELT FAN AND HUB RING TO FAN COUPLING
999
SPACER WASHER BELT TIGHTENER 0.20 MM
999
SPACER WASHER BELT TIGHTENER 0.50 MM
999
SPACER WASHER BELT TIGHTENER 1.00 MM
999
SPACER WASHER BELT TIGHTENER 0.20 MM
999
SPACER WASHER BELT TIGHTENER 0.20 MM
999
SPACER WASHER BELT TIGHTENER 1.00 MM
999
EXPANSION PLUG BELT TIGHTENER
999
GREASE NIPPLE
999
LOCK RING BELT TIGHTENER
999
LOCK RING BELT TIGHTENER
