Поз.
Артикул
Описание
3
BEARING BODY FAN DRIVE
3
BEARING BODY FAN DRIVE
3
BEARING BODY FAN DRIVE
8
SCREW ,R 034014
11
WASHER TRAILER PLUG SOCKET TO BRACKET
14
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
15
FAN SHAFT
15
FAN SHAFT ,D 180260
15
FAN SHAFT ,D 276362
18
CYLINDR. ROLLER BEARING FAN DRIVE
21
LOCK RING52X2 MM
26
BALL BEARING. GROOVED BALL BEARING FAN DRIVE,D 276362
26
BALL BEARING FAN DRIVE
27
SPACER TUBE
29
SEAL RING CASE COVER
29
SEAL RING
29
RADIAL SEAL RING
30
NUT SPRING SEAT AND BEARING BRACKET TO REAR AXLE
31
PULLEY FAN DRIVE
31
PULLEY FAN
34
GREASE NIPPLE
34
GREASE NIPPLE PROTECTIVE TUBE
45
FAN
51
SCREW LINES TO BRACKET
55
LOCK
65
LEVER BELT TIGHTENER PULLEY
68
PIN BELT TIGHTENER
71
PULLEY BELT TIGHTENER PULLEY
71
PULLEY BELT TIGHTENER PULLEY
74
BALL BEARING BELT TIGHTENER PULLEY
74
BALL BEARING BELT TIGHTENER PULLEY
80
STAY ,D 180260
80
STAY TIGHTENER PULLEY,D 196082
83
SPACER TUBE BELT TIGHTENER PULLEY
86
SEAL RING BELT TIGHTENER PULLEY
98
EXPANSION PLUG BELT TIGHTENER PULLEY
99
LOCK BELT TIGHTENER PULLEY
100
HUB BELT TIGHTENER PULLEY
101
SCREW BELT TIGHTENER PULLEY
104
NUT BRACKET TO SIDE MEMBER
105
WASHER , Replaced By: N000125008443
107
NUT HUB CAP TO BRACKET
108
WASHER , Replaced By: A3829907140
109
SUPPORT ,D 196082
113
WASHER , Replaced By: N000125017016
116
NUT
117
GREASE NIPPLE INTERMEDIATE LEVER
119
NEEDLE BEARING (TIGHTENER ARM)
122
PIN
122
PIN (TIGHTENER ARM)
125
LOCK
128
SCREW EXHAUST BRAKE SEPARATION POINT
131
WASHER (TIGHTENER ARM)
131
WASHER (TIGHTENER ARM)
131
WASHER (TIGHTENER ARM)
137
GREASE NIPPLE INTERMEDIATE LEVER
143
SCREW ANGLE TO CROSS MEMBER M 10X30
143
SCREW , Replaced By: N304017010040
146
WASHER A. WASHER BRACKET TO LEFT SIDE MEMBER
146
WASHER GROUND CABLE
149
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
150
V-BELT
150
V-BELT SET2 PIECES 12.5X1400, UP TO CHASSIS D 164887 EXCEPT FOR:D 162653,D 162907,D 163135,D 163292,D 164695.
151
V-BELT SET2 PIECES 12.5X1600,D 180260
151
V-BELT FROM VIBRATION DAMPER TO TIGHTENER PULLEY,D 173028
151
V-BELT SET2 PIECES 12.5X1600,D 180261D 196082
151
V-BELT FROM TIGHTENER PULLEY TO FAN DRIVE 1725 MM,D 180261D 434768
