Поз.
Артикул
Описание
5
VALVE (PRESSURE LIMIT VALVE) 3.5 BAR
6
VALVE PRESSURE REGULATOR
7
8
FITTING LINE CONNECTION
8
FITTING AIR RESERVOIR,CONNECTION: "15",5 433280
9
CONNECTOR SOLENOID VALVE,CONNECTION: "2"
10
FITTING , Replaced By: A0019909871
11
SCREW. UNION SCREW LINE CONNECTION
12
PRESSURE REGULATOR AT FOUR-CIRCUIT PROTECTIVE VALVE KNORR
13
14
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
17
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
20
THRUST RING CHECK VALVE TO AIR RESERVOIR
20
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
23
O-RING CHECK VALVE TO AIR RESERVOIR
32
VALVE (SOLENOID VALVE) WABCO
32
VALVE. PIN "TOP-BRAKE", Replaced By: A0059971236
32
VALVE (3/2-WAY SOLENOID VALVE) ENGINE SHUT-OFF WABCO
32
VALVE 3/2-WAY VALVE
33
REPAIR KITTO 003 997 14 36,WABCO 472 123 19 80
34
FITTING LINE CONNECTION
35
CONNECTOR REAR AXLE VALVE,CONNECTION: "1"
38
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
38
SEAL RING , Replaced By: A0009940747
41
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
41
LOCK , Replaced By: A0009945448
44
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16 ,VOSS 232
44
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M 22, VOSS 232
44
SCREW. UNION SCREW LINE CONNECTION
44
SCREW. UNION SCREW , Replaced By: A0009973734
45
SCREW TO LOCK SOLENOID VALVE, Replaced By: N000084006132
46
SEAL RING TO LOCK SOLENOID VALVE 7X12MM
47
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
47
THRUST RING LOCKING VALVE
47
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
47
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
47
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
50
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
50
THRUST RING CHECK VALVE TO AIR RESERVOIR
53
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
53
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
56
O-RING CHECK VALVE TO AIR RESERVOIR
65
NUT AIR RESERVOIR,CONNECTIONS: "14,21,35"
67
SCREW-IN FITTING
71
SEAL RING , Replaced By: A0009940747
80
LOCK , Replaced By: A0009945448
83
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16 ,VOSS 232
83
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M 22, VOSS 232
83
SCREW. UNION SCREW , Replaced By: A0009973734
88
BRACKET 3/2-WAY VALVE
88
BRACKET MOUNTING SOLENOID VALVE
89
SCREW. HEXAGON HEAD BOLT FRONT EXHAUST PIPE TO MUFFLER M8X110 - TO A 979 492 03 40
89
SCREW. HEXAGON HEAD BOLT GGVS-COMPONENT IN BATTERY CARRIER M8X55
91
HEXAGON HEAD BOLT. SCREW MOUNTING PARTS M 14X1.5X35
91
SCREW , Replaced By: N910143008010
92
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
92
NUT HORN TO BRACKET M8
95
95
COMPRESSED AIR DRIER VALVE CLUSTER KNORR
95
ANTI-FREEZE DEVICE VALVE CLUSTER KNORR, Replaced By: A3824310015
95
COMPRESSED AIR DRIER VALVE CLUSTER KNORR
95
ANTI-FREEZE DEVICE VALVE CLUSTER KNORR
95
109
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) KNORR,D 521240
111
VALVE EXHAUST BRAKE TO382 42073 71, NOT USED
126
VALVE REPAIR KIT KNORR
132
133
REPAIR KIT VALVE TO 000 420 46 71
138
NUT
149
SCREW PLUG SOLENOID VALVE M16
149
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
149
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
152
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
152
O-RING CHECK VALVE TO AIR RESERVOIR
155
THRUST RING CHECK VALVE TO AIR RESERVOIR
155
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
155
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
158
HEXAGON HEAD BOLT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER M14X1.5X40
158
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
158
HEXAGON HEAD BOLT BEARING BRACKET TO SIDE MEMBER M14X1.5X100
158
HEXAGON HEAD BOLT. SCREW MOUNTING PARTS M 14X1.5X35
161
NUT SPRING CLAMP
161
NUT SHOCK ABSORBER
164
SCREW-IN FITTING RELAY VALVE,CONNECTIONS: "32,34"
180
SWITCH TWO-CIRCUIT BRAKE VALVE
182
184
SENDER UNIT FOUR-CIRCUIT PROTECTIVE VALVE
187
SOLENOID VALVE 3/2-WAY VALVE ADBLUE
187
VALVE (3/2-WAY SOLENOID VALVE)
200
VALVE PRESSURE LIMIT VALVE
210
RS PROTECTION VALVE
220
RS PROTECTION VALVE INTERMEDIATE CASE KNORR
230
RS PROTECTION VALVE PISTON KNORR
