Поз.
Артикул
Описание
161
BRAKE HOSE AT FRONT BRAKE CYLINDER
170
TEST CONNECTION TIRE INFLATING CONNECTION KNORR
170
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
170
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
170
TEST CONNECTION
173
FITTING DELIVERY LINE TO PUMP
176
ADAPTER FITTING TEST CONNECTION
179
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
179
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
179
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
179
THRUST RING LOCKING VALVE
180
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
182
SEAL RING ,D 031294
188
SEAL RING AT REAR AXLE,D 248571
188
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
194
ELBOW FITTING DIAPHRAGM CYLINDER,CONNECTION: "1,11"
195
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
195
FITTING QUICK BREATHER VALVE,REAR, CONNECTION: "23"
197
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
200
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M 22, VOSS 232
200
SCREW. UNION SCREW LINE CONNECTION
201
SCREW. UNION SCREW , Replaced By: A0009973734
201
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16 ,VOSS 232
203
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
204
LOCK , Replaced By: A0009945448
206
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
207
SEAL RING , Replaced By: A0009940747
208
NUT ,D 091466
208
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
209
WASHER SUPPORT TO FRAME,D 127794
210
TOOTHED WASHER ELECTRIC CABLE TO FUSE BOX
211
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
212
T-FITTING FROM PRESSURE REGULATOR TO T-FITTING
230
ADAPTER FITTING LINE CONNECTION TO ENGINE
236
WASHER COILED TUBE TO BRAKE LINE COUPLING SUPPORT
239
TOOTHED WASHER SENDER UNIT TO BRACKET
242
NUT BRACKET TO SIDE MEMBER
260
260
DISTRIBUTOR REAR AXLE
278
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M 22, VOSS 232
